TO THE SERVICE MAN:
The 4F40 chassis is an AC, DC or battery operated super-
heterodyne. The chassis is isolated iron: the DC circuit,
and all measurements met he made from a cm nega-
tive point. The most convenient place to reach this nega-
tive point is the terminal strip to which C17 is connected.
When the change over Switch 51 is in AC position, the DC
resistance {rem chassis to any circuit must be almost in-
finite. If any circuit becanos grounded a hum Will result.
Microphonic tubes will cause audio howl. Check the 1115
and 155.
The WW is connected to the chassis by two wires
that pass through the hollow dial pivots. If the R.F. be-
comes week or dead. check the D.C. resistance of the
wavunagnet. This D.C. resistance should be approximate-
ly .9 ohm. If it is Open check the wavemagnet.
3 IF Alignment: Remove the chassis from the cabinet and
arrange the units so that the wavemagnet can be connected.
All the connections and adjustments can he mace Item the
top of the chassis. Contact a signal generator, through a
.1 mid. dummy antenna. to the converter grid ma 8 -
(common return). Connect an output meter across the
voice mile! the Speaker (two lugs provided). Set the sig-
nal generator to 455 Kc. and adjust L3. L4. L5 and L6 for
maximum indication on the outtpm meter. Always keep the
signal wtpot from the generator just high enough to get an
I indication, otherwise excessive loading my result.
RF Alignment: Connect a two turn loop across the leads
of the signal generator. loosely couple this loop to the
wovemagnet. Set the signal generator and the dial point-
er of the receiver to 1600 Kc. and adjust CS oscillator
trio-one: to resonance. Set the signal generator and dial
pointer to 1400 and adjust C2 antenna trimmer to reson-
ance. These trimmers are on the top of gang condenser.
Check operation and re-install set in cabinet. Tune too
weak station near 1400 Kc. or use background noise and
readjust antenna trimmer for maximum sensitivity.
mun act-we Ml!
sou mm mm-
L$ alum x.
L6 socrorH
m mm.
455.
ON-o" switch!
6
TUBEJRIMMER lOCA'I'ION
351' If. TRANS.
65 KC.
L... @
®
lilo
-_.-:Hv - _ v-W
I .
e ' _ .
L3 FRI. 00710
LA SECTO?
VOLUH CD). TROL
TUNING
ALIGNMENT PROCEDURE
