Yamaha yst sw011
This is the 18 pages manual for yamaha yst sw011.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from yamaha yst sw011 (Ocr-read)
Page 1
YST-SW011 2 YST-SW011 WALL OUTLETEQUIPMENT UNDER TESTAC LEAKAGE TESTER OR EQUIVALENT INSULATING TABLE TO SERVICE PERSONNEL 1. Critical Components Information Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only) When service has been completed, it is imperative to verify that all exposed conductive surfaces are properly insulated from supply circuits. Meter impedance should be equivalent to 1500 ohms shunted by 0.15µF. CAUTION F1: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE 1.6A, 125V FUSE. CAUTION F1: REPLACE WITH SAME TYPE 1.6A, 125V FUSE. ATTENTION F1: UTILISER UN FUSIBLE DE RECHANGE DE MEME TYPE DE 1.6A, 125V. WARNING: CHEMICAL CONTENT NOTICE! The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and /or plastic (where applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and possibly other entities) to cause cancer and/or birth defects or other reproductive harm. DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REA- SON WHATSOEVER! Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes to solder/flux vapor! If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food. Leakage current must not exceed 0.5mA. Be sure to test for leakage with the AC plug in both polarities. About Lead Free Solder / ÁËï¼tmMo Side A Side BSMT REFLOW Process MI FLOW Process Solder Dip ÁËï¼txMXmTw ¨UK‡bUz .gÌtx<Gw OsÁËï¼w–;› * `‡b{ ~ 4 O " H $ V¢ Ü £ ~ 4 O $ V¢ £ ~ 4 O ; O # J
Page 2
YST-SW011 3 YST-SW011 SPECIFICATIONS / ۧ7 Type /
