RX-V477/HTR4067

I TO SERVICE PERSONNEL

1. Critical Components information

Components having special characteristics are marked A: and
must be replaced with parts having specifications equal to
those originally installed,

2. Leakage Current Measurement (For 120V Models Only)

When service has been completed, it is imperative to verify
that all exposed conductive surfaces are properly insulated
from supply circuits

0 Meter impedance should be equivalent to fSOO ohms shunted
by O.f5 uF,

For U model
IEEI CAUTION"

AC LEAKAGE
WALL EQUiPMENT TESTER OR
OUTLET UNDER TEST EQUIVALENT

o :3- ,

J.-

iNSULATiNG
TABLE

- Leakage current must not exceed 0.5mA,
- Be sure to test for leakage withthe AC plug in both polarities,

-A-V "F5401: FOR CONTiNUED PROTECTiON AGAINST RISK OF FiRE, REPLACE ONLY WiTl-l SAME TYPE 2A,

250V FUSE,

F5402: FOR CONTiNUED PROTECTiON AGAINST RISK OF FiRE, REPLACE ONLY WiTi-l SAME TYPE 6A,

125V FUSE,

For C model
CAUTION

F540i: REPLACE WITH SAME TYPE 2A, 250V FUSE
F5402: REPLACE WlTl-l SAME TYPE 5A, 125V FUSE

ATTENTION

F5401: UTiLiSER UN FUSIBLE DE RECl-lANGE DE MEME TYPE DE 2A, 250V.
F5402: UTiLiSER UN FUSIBLE DE RECl-lANGE DE MEME TYPE DE 6A, i25V.

WARNING: CHEMICAL CONTENT NOTICE!

This product contains chemicals known to the State of California to cause cancer, or birth defects or other reproductive

harm.

DO NOT PLACE SOLDER, ELECTRiCAL/ELECTRONIC OR PLASTIC COMPONENTS iN YOUR MOUTl-l FOR ANY REASON

WHATSOEVER!

Avoid prolonged, unprotected contact between solder and your skini When soldering, do not inhale solder fumes or

expose eyes to solder/flux vapor!

if you come in contact with solder or components located inside the enclosure of this product, wash your hands before

handling food.

About lead free solder/fifiEHVjIEDLT

All of the P,C.B.s installed in this unit and solder joints are
soldered using the lead free solder,

Among some types of lead free solder currently available,
it is recommended to use one of the following types for
the repair work,

0 Sn + Ag + Cu (tin + silver + copper)

I Sn + Cu (tin + copper)

0 Sn + Zn + Bi (tin + zinc + bismuth)

Cautlon:

As the melting point temperature of the lead free solder is
about 30° C to 40° C (50° F to 70° F) higher than that of
the lead solder, be sure to use a soldering iron suitable to
each solder.
