I TO SERVICE PERSONNEL
1. Critical Components Information.
Components having special characteristics are marked and AC LEAKAGE I
must be replaced with parts having specifications equal to WALL EQUIPMENT TESTEFl on
those originally installed. OUTLET UNDER TEST EQUIVALENT
2. Leakage Current Measurement (For 120V Models Only). :3
When service has been completed, it is imperative to verify ®
that all exposed conductive surfaces are properly insulated
from supply circuits. . E =
INSULATING
0 Meter impedance should be equivalent to 1500 ohm shunted TABLE
by 0.1 stir. ,
o Leakage current must not exceed 0.5mA.
0 Be sure to test for leakage with the AC plug in both
polarities.
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or I
plastic (where applicable) components may also contain traces oi chemicals found by the California Health and
Welfare Agency (and possibly other entities) to cause cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAUELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR
ANY REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or
expose eyes to solder/flux vapor!
It you come in contact with solder or components located inside the enclosure of this product, wash your hands
before handling food.
I REMOTE CONTROL PANEL
