Yamaha psr s550 s550b servicemanual
This is the 69 pages manual for yamaha psr s550 s550b servicemanual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from yamaha psr s550 s550b servicemanual (Ocr-read)
Page 1
2PSR-S550/PSR-S550B IMPORTANT NOTICE This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically Yamaha Products, are already known and understood by the users, and have therefore not been restated. WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in per- sonal injury, destruction of expensive components and failure of the product to perform as specified. For these reasons, we advise all Yamaha product owners that all service required should be performed by an authorized Yamaha Retailer or the appointed service representative. IMPORTANT: This presentation or sale of this manual to any individual or firm does not constitute authorization certifi- cation, recognition of any applicable technical capabilities, or establish a principal-agent relationship of any form. The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research engineering, and service departments of Yamaha are continually striving to improve Yamaha products. Modifications are, therefore, inevitable and changes in specification are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division. WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have accumulated by grounding yourself to the ground bus in the unit (heavy gauge black wires connect to this bus.) IMPORTANT: Turn the unit OFF during disassembly and parts replacement. Recheck all work before you apply power to the unit. WARNING: This product contains chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm. DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON WHAT SO EVER! Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes to solder/ flux vapor! If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food. SAVING DATA Saving and backing up your data The panel settings and some other types of data are not retained in memory when you turn off the power to the instrument. Save data you want to keep to the Registration Memory. Saved data may be lost due to malfunction or incorrect operation. Save important data to a USB storage device/or other external device such as a computer. Be sure toperform it Backing up the USB storage device/external media To protect against data loss through media damage, we recommend that you save your important data onto two USB storage devices/external media. Be sure toperform it Components having special characteristics are marked and must be replaced with parts having specification equal to those originally installed. WARNING
Page 2
3 PSR-S550/PSR-S550B ■ SPECIFICATIONS Keyboards-61 Standerd-size keys (C1–C6), with Touch Response. Display-320 x 240 dots LCD display (backlit) Setup-STANDBY/ON -MASTER VOLUME: MIN–MAX -LCD CONTRAST Panel Controls -DEMO, SONG MODE -SONG-PRESET, SONG-USER, SONG-SCORE, SONG-LYRICS, SONG-REC -STYLE CATEGORY, VOICE CATEGORY -TRANSPOSE [-] [+], METRONOME, TAP TEMPO, TEMPO [-] [+] -OTS LINK, AUTO FILL IN, ACMP, INTRO [1]–[3], MAIN VARI- ATION [A]–[D], ENDING/rit. [1]–[3] (REW) (FF), SYNC STOP (A-B REPEAT), SYNC START (PAUSE), START/STOP -REGIST/PART [MIXER], MEMORY, REGIST BANK [-] [+], REGISTRATION MEMORY [1]–[8], STYLE [1] -[8], SONG [1/9] -[8/16], EXIT, CATEGORY [ ] [ ], Dial, [+/YES] [-/NO] -EXECUTE, MDB, FILE MENU, FUNCTION, ONE TOUTCH SETTING [1]–[4], LEFT, DUAL, HARMONY, TOUCH, SUSTAIN, DSP, UPPER OCTAVE [-] [+] Realtime Control-Pitch Bend Wheel Voice-294 Voices + 12 Drum Kits + 10 SFX Kits + 480 XG Voices (Included 11 Regional Voices and 8 Regional Drum/Percussion Kits) -Polyphony: 64 -LEFT -DUAL Style-176 -Style Control: ACMP ON/OFF, SYNC STOP, SYNC START, START/STOP, INTRO [1]–[3], MAIN VARIA- TION [A]–[D], ENDING/rit. [1]–[3], AUTO FILL IN -Fingering: Multi Finger, Full Keyboard -Style Volume Music Database-600 Registration Memory-8 banks x 8 memories -Regist Clear Effects-Harmony: 26 types -Reverb: 35 types -Chorus: 44 types -DSP: 237 types Song-5 Preset Songs + User Songs + USB Memory-Song Clear, Track Clear -Song Volume -Song Control: A-B REPEAT, PAUSE, REW, FF, START/STOP Recording-Song User Song: 5 Songs Recording Tracks: 1 -16, STYLE MIDI-Local On/Off - Initial Setup - External Clock -Keyboard Out - Style Out - Song Out Auxiliary jacks-PHONES/OUTPUT, DC IN 16V, USB TO HOST, USB TO DEVICE, SUSTAIN Amplifier-12W x 2 Speakers-(12cm + 3cm) x 2 Power Consumption-25W Power Supply-Adaptor: Yamaha PA-301 or PA-300 AC power adaptor Dimensions (W x D x H)-946 x 402 x 130 mm (37-1/4" x 15-7/8" x 5-1/8") Weight-7.5kg (16 lbs., 9 oz.) Supplied Accessories-Music Rest - Accessory CD-ROM -Keyboard Stand: L6 -Foot Switch: FC4/FC5 - Owners Manual -AC Power adaptor (May not be included depending on your par- ticular area.) Optional Accessories -Headphones: HPE-150 -Style Creator Function-VOLUME: Style Volume, Song Volume -OVERALL: Tuning, Pitch Bend Range, Split Point, Touch Sensitivity, Chord Fingering -MAIN VOICE: Volume, Octave, Pan, Reverb Level, Chorus Level, DSP Level, Dry Level -DUAL VOICE: Volume, Octave, Pan, Reverb Level, Chorus Level, DSP Level, Dry Level -LEFT VOICE: Volume, Octave, Pan, Reverb Level, Chorus Level, DSP Level, Dry Level -EFFECT: Reverb Type, Chorus Type, DSP Type, Master EQ Type -HARMONY: Harmony Type, Harmony Volume -PC: PC Mode -MIDI: Local On/Off, External Clock, Keyboard Out, Style Out, Song Out, Initial Setup -METRONOME: Time Signature Numerator, Time Signature Denominator, Bell On/Off, Metronome Volume -SCORE: Quantize, Right-Part, Left-Part -UTILITY: -LANGUAGE: LanguageDemo Cancel, TG Mode Mixer-Volume, Pan, Reverb, Chorus -Style Creator -USB
