Yamaha ns 150
This is the 4 pages manual for yamaha ns 150.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from yamaha ns 150 (Ocr-read)
Page 1
1 23 4 7 10 11 11 1115 16 15 16 1-5 1-24 201 206 205 204 202 203x4 x4 x4 x4 x4 x1 1-1-6 1-1-9 1-1-8 1-1-7 1-1-15 NS-150 EXPLODED VIEW ABCDE 1 2 3 4 5 6 7Use an Allen wrench (3mm) to unscrew the loud speaker.
Page 2
PARTS LIST * 1 V6120000 CABINET ASSY CH * 1 V6120200 CABINET ASSY BL * 1-1-6 V6615600 ELECTROLYTIC CAP 33uF 63V 1-1-7 V5370100 ELECTROLYTIC CAP 6.8uF 50V 1-1-8 V5357100 ELECTROLYTIC CAP 4.7uF 50V 1-1-9 CB818540 BINDING TIE T-30RF-2 1-1-15 EP030200 BIND HEAD TAPPING SCREW 3x8 ZMC2-Y 1-5 CB605250 HOLDER 1-24 CB070450 BINDING TIE L=100 L=100 2 V5383200 FRONT GRILLE ASSY CH 2 V5383400 FRONT GRILLE ASSY BL 3 XW232A00 LOUD SPEAKER 3cm 6 Ω 50W 4 XY380A00 LOUD SPEAKER 13cm 12 Ω 30W * 7 V6261100 SPEAKER TERMINAL 10 V5537900 OVAL HEAD TAPPING SCREW #1 3.5x16 MFZN2BL 11 V5537800 HEXAGON SOCKET TAPPING SCREW 4x20 MFZN2BL 15 V5361400 TERMINAL CAP S06E RED 16 V5361500 TERMINAL CAP S06E BLACK ACCESSORIES 201 V5004900 STAND ASSY 1pc/set 202 V5386900 SPIKE x1 M6x15 203 V2450400 HEXAGONAL NUT x1 6mm MFZN2-BL * 204 V6075800 LEG ASSY 4pcs/set 205 EP040250 BIND HEAD TAPPING SCREW 4x16 ZMC2-BL 206 EG360010 BIND HEAD SCREW 6x16 MFC2BL * New Parts Ref. No. PART NO. Description Remarks Markets NS-150
