Page 1
NS-90/C120/120 168(6-5/8") 177(7")156(6-1/8") 21(13/16")60(2-3/8") 40(1-9/16") 54 (2-1/8") 160(6-5/16") 310(12-3/16") Unit : mm (inch) 480(18-7/8") 171(6-3/4") 150(5-7/8") 21(13/16") 140(5-1/2") Unit : mm (inch) 168(6-5/8") 269(10-9/16")250(9-13/16") 19(3/4") 800(31-1/2") 612(24-1/16") Unit : mm (inch) DIMENSIONS 1 NS-90 NS-C120 NS-120
Page 2
NS-90/C120/120 L1C1 BE BL RE BLYE BL TERMINAL TWEETER WOOFER C2L2 L1C1 BE BL RE BL RE BLYE BL TERMINAL TWEETER WOOFER WOOFER C2L2 L1C1 BE BL RE BLYE BL TERMINAL TWEETER WOOFER C2L2 INPUT WOOFER TWEETER 3.3 F 10 F 0.35mH 1.5mH INPUT WOOFER TWEETER 4.7 F 8.2 F WOOFER 0.3mH 1.0mH INPUT WOOFER TWEETER 4.7 F 6.8 F 0.4mH 1.2mH 2 NETWORK CIRCUIT DIAGRAMWIRING DIAGRAM NS-90 NS-C120 NS-120NS-90 NS-C120 NS-120
