KX-800/800U
I TO SERVICE PERSONNEL
1. Critical Components Information.
Components having special characteristics are marked
and must be replaced with parts having specifications equal
to those originally installed.
2. Leakage Current Measurement (For 120V Model Only).
When service has been earripleted, it is imperative that you
verify that all exposed conductive surfaces are properly
insulated from supply circuits.
0 Meter impedance should be equivalent to 1500 ohm shunted
bv 0.15uF.
0 Leakage current must not exceed 0.5mA.
0 Be sure to test for leakage with the AC plug in both polarities.
