AV RECEIVER

RX-V471/HTR-4064

SERVICE MANUAL

IMPORTANT NOTICE \

This manual has been provided for the use of authorizedYAMAHA Retailers and their service personnel.

It has been assumedthat basic service procedures inherent to the industry, andmore specifically YAMAHA Products, are already known

and understood by the users, andhave therefore not been restated.

WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury,
destruction of expensive components, and failure ofthe product to perform as specified. For these reasons, we advise
all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or

the appointed service representative.
IMPORTANT: The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please contact the

distributor's Service Division.

WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black Wires connect to this buss).

IMPORTANT: Turn the unit OFF during disassembly andpart replacement. Recheck all work before you apply power to the unit. /

I CONTENTS

TO SERVICE PERSONNEL ............................................ 2 DISPLAY DATA ....................................................... 58-59
FRONT PANELS ............................................................. 3 IC DATA ................................................................... 60-70
REAR PANELS ........................................................... 4-7 BLOCK DIAGRAM ........................................................ 71
REMOTE CONTROL PANELS ....................................... 8 PRINTED CIRCUIT BOARDS ................................. 72-89
SPECIFICATIONS léfifijfi ................................... 9-14 PIN CONNECTION DIAGRAMS ................................... 90
INTERNAL VIEW .......................................................... 15 SCHEMATIC DIAGRAMS ..................................... 91-103
SERVICE PRECAUTIONS I If- EXfiwiifigg ..... 15 REPLACEMENT PARTS LIST ............................ 105-121
DISASSEMBLY PROCEDURES lfi'fifiafllfi ........... 16-18 REMOTE CONTROL ........................................... 122-124
UPDATING FIRMWARE] CONFIGURING THE SYSTEM SETTINGS ................. 125
77-14717037-17-73- I~ ------------------------------ 19-20 9X?L\$§EEEE¢% --------------------------------------------- 125
SELF-DIAGNOSTIC FUNCTION /

547? (fiaifififififi) ....................................... 21-57

:0v-Ez-«:;7»u. I :I-r-ailimfiifiiwfl L'cmé 1'.
This Service Manual uses recycled paper.

II
5
<
a:
-4
-L
I-
I
_|
3P
a:
D
0!
a:
