Yamaha dvd s830

Page 1

DVD PLAYER

DVD-$830

SER

E MANU

IMPORTANT NOTICE

This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
it has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products. are already
known and understood by the users. and have therefore not been restated.

WARNING: Failure to follow appropriate service and safety procedures when servtcing this product may result in personal
injury, destruction of expensive components. and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.

IMPORTANT: The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities. or establish a principierngenl relationship of any form.

The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research. engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are. therefore. inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist. please

Contacl Ihe distributor's Service Division.

WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
IMPORTANT: Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.

I CONTENTS

TO SERVICE PERSONNEL ....................................
PREVENTION OF ELECTRO STATIC DISCHARGE
LOCALE MANAGEMENT INFORMATION
FRONT PANELS
REAR PANELS .....
REMOTE CONTROL PANEL
SPECIFICATIONS ....................
DISASSEMBLY PROCEDURES AND

SERVICE POSITION ................................................ 7~11
OPTICAL PICKUP SELF-DIAGNOSIS AND
REPLACEMENT PROCEDURE ............................ 12~13
SELF-DIAGNOSIS FUNCTION AND

SERVICE MODES .................................................. 14~19

waI-b-h-hw

I Lowe EX7:17)H:L137*733Ewfiifiéfifi burst.
Thts Service Manual uses recycled paper

100825

ASSEMBLING AND DISASSEMBLING THE
MECHANISM UNIT
ADJUSTMENT
BLOCK DIAGRAM

INTERCONNECTION SCHEMATIC DIAGRAM . 40
ABBREVIATIONS. . 41
PRINTED CIRCUIT BOARD. 42~53
SCHEMATIC DIAGRAM . 54~82
VOLTAGE CHART 83~94
PARTS LIST. 95~102
Parts List for Chip Carbon ReSistors ..... 103
Parts List for Carbon Resistors .............................. 104

YAMAHA

YAMAHA CORPORATION

P.O.Box 1. Hamamatsu, Japan

D
<
'.3
tn
Q
(a)
O

Page 2

DVD-$830

DVD-S830

1I TO SERVICE PERSONNEL AC LEAKAGE
WALL EQUIPMENT TESTER OR
.Critical Components Information OUTLET UNDER TEST EQUIVALENT
Components having special characteristics are marked l
and must be replaced with parts having specifications equal
to those originally installed. ® :ID-
2. Leakage Current Measurement (For 120V Models Only) J_-

When service has been completed, it is imperative to verify
that all exposed conductive surfaces are properly insulated
from supply circuits.

INSULATING
TABLE

0 Meter impedance should be equivalent to 1500 ohm shunted ° Leakage current 151 OI exceed 0.5mA.

by 0.15pF. 0 Be sure to test for leakage with the AC plug in both polarities.

WARNING: CHEMICAL CONTENT NOTICE!

The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (where
applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and
possibly other entities) to cause cancer and/or birth defects or other reproductive harm.

DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REA-
SON WHATSOEVER!

Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose
eyes to solder/flux vapor!

If you come in contact with solder or components located inside the enclosure of this product, wash your hands before
handling food.

WARNING: Laser Safety

This product contains a laser beam component. This component may emit invisible, as well as visible radiation, which may
cause eye damage. To protect your eyes and skin from laser radiation, the following precautions must be used during
servicing of the unit.

1) When testing and/or repairing any component within the product, keep your eyes and skin more than 30 cm away from
the laser pick-up unit at all times. Do not stare at the laser beam at any time.

2) Do not attempt to readjust, disassemble or repair the laser pick-up, unless noted elsewhere in this manual.

3) CAUTION : Use of controls, adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.

Laser Emitting conditions:

1) When the Top Cover is removed, and the "STANDBY/ON" SW is turned to the ON" position, the laser component will
emit a beam for several seconds to detect if a disc is present. During this time (5-10 sec.) the laser may radiate through
the lens of the laser pick-up unit. Do not attempt any servicing during this period!

If no disc is detected, the laser will stop emitting the beam. When a disc is set, you will not be exposed to any laser
emisswns.

2) The laser power level can be adjusted with the VR on the pick-up PWB. However, this level has been set by the factory
prior to shipping from the factory. Do not adjust this laser level control unless instruction is provided elsewhere in this
manual.

Adjustment of this control can increase the laser emission level from the device.

Laser Diode Properties
Type: Semiconductor laser GaAlAs
Wave length: 658 nm (DVD)
790 nm (VCD/CD)
Output Power: CLASS IIa th (DVD)
CLASSI 1mW (VCD/CD)
