Yamaha dv s5450
This is the 90 pages manual for yamaha dv s5450.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from yamaha dv s5450 (Ocr-read)
Page 1
DVD-S520/DV-S5450 DVD-S520/DV-S5450 1 WALL OUTLET EQUIPMENT UNDER TEST AC LEAKAGE TESTER OR EQUIVALENT INSULATING TABLE WARNINGS WARNING: CHEMICAL CONTENT NOTICE! The solder used in the production of this product contains LEAD. In add\ ition, other electrical/electronic and /or plastic (where applicable) components may also contain traces of chemicals fou\ nd by the California Health and Welfare Agency (and possibly other entities) to cause cancer and/or birth defects or \ other reproductive harm. DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR\ MOUTH FOR ANY REA- SON WHATSOEVER! Avoid prolonged, unprotected contact between solder and your skin! When\ soldering, do not inhale solder fumes or expose eyes to solder/flux vapor! If you come in contact with solder or components located inside the encl\ osure of this product, wash your hands before handling food. WARNING: Laser Safety This product contains a laser beam component. This component may emit in\ visible, as well as visible radiation, which may cause eye damage. To protect your eyes and skin from laser radiation, th\ e following precautions must be used during servicing of the unit. 1) When testing and/or repairing any component within the product, keep you\ r eyes and skin more than 30 cm away from the laser pick-up unit at all times. Do not stare at the laser beam at a\ ny time. 2) Do not attempt to readjust, disassemble or repair the laser pick-up, unl\ ess noted elsewhere in this manual. 3) CAUTION: Use of controls, adjustments or performance of procedures other\ than those specified herein may result in hazardous radiation exposure. Laser Emitting conditions: 1) When the Top Cover is removed and the "POWER" SW is turned to the "ON" p\ osition, the laser component will emit abeam for several seconds to detect if a disc is present. During this tim\ e (5 - 10 sec.) the laser may radiate through the lens of the laser pick-up unit. Do not attempt any servicing during this peri\ od! If no disc is detected, the laser will stop emitting the beam. When a di\ sc is loaded, you will not be exposed to any laser emissions. 2) The laser power level can be adjusted with the VR on the pick-up PWB. Ho\ wever, this level has been set by the factory prior to shipping from the factory. Do not adjust this laser level contr\ ol unless instruction is provided elsewhere in this manual. Adjustment of this control can increase the laser emission level from th\ e device. TO SERVICE PERSONNEL 1. Critical Components Information Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only) When service has been completed, it is imperative to verify that all exposed conductive surfaces are properly insulated from supply circuits. Meter impedance should be equivalent to 1500 ohm shunted by 0.15 µF. Leakage current must not exceed 0.5mA. Be sure to test for leakage with the AC plug in both polarities. THE DVD PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPE\ RLY QUALIFIED SERVICE PER- SONNEL.
Page 2
DVD-S520/DV-S5450 DVD-S520/DV-S5450 U, C modelsB, G models R, A, T, P models CAUTION - Visible and invisible laser radiation when open. Avoid exposure to beam. DANGER - Visible and invisible laser radiation when open. Avoid direct exposure to beam. CAUTION - Visible and invisible laser radiation when open. Avoid exposure to beam. 2 Laser Diode Properties Type: Semiconductor laser GaAlAs Wave length: 650 nm (DVD) 780 nm (VCD/CD) Output Power: 7 mW (DVD) 10 mW (VCD/CD) Beam divergence: 60 degree Output value is determined by CFR CHAPTER1, SUBCHAPTER J VARO! : AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄkymÄTTÖ\ MÄLLE LASER- SÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN. VARNING! : OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRRE\ N ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN. WARNING The use of optical instruments with this product will increase eye hazar\ d. Repair handling should take place as much as possible with a disc loaded\ inside the player WARNING LOCATION: REAR PANEL CAUTION VISIBLE AND INVISIBLE LASER RADIATI ON WHEN OPEN. AVOID EXPOSURE TO BEA\ M ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING UNDGÅ UDSÆTTELSE\ FOR STRÅLING ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES UNNGÅ EKS\ PONERING FOR STRÅLEN VARNING SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR Ö\ PPNAD BETRAKTA EJ STRÅLEN VARO! AVATT AESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄ\ LLE LASER SÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN VORSICHT SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET NIC\ HT DEM STRAHL AUSSETSEN DANGER VISIBLE AND INVISIBLE LASER RADIATI ON WHEN OPEN. AVOID DIRECT EXPOSURE\ TO BEAM ATTENTION RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS D'OUVERTURE EXPO\ SITION DANGEREUSE AU FAISCEAU Warning for power supply The primary side of the power supply including the heatsink carries live\ mains voltage when the player is connected to the mains even when the player is switched off ! This primary area is not shielded so it is possible to touch copper trac\ ks and/or components when servicing the player. Service personnel have to take precautions to prevent touching this area\ or components in this area . The primary side of the power supply has been indicated with a lightenin\ g stroke and a stripe-marked print on the printed wiring board Note: The screws on the DVD mechanism (position 18-1 in on the exploded view \ drawing) may never be touched, removed or re-adjusted. Handle the DVD mechanism with care when the unit has to be exchanged! The DVD mechanism is very sensitive for dropping or giving shocks.
