Yamaha cs 10 cs 30 cs 30l patch charts

Page 2

The new sounds made available to us by the emergence of the synthesizer have
made possible the opening up of an entirely new genre in the world of music. And
we hope that you, as one who loves music, will be able to make this wonderful
world of new possibilities yours soon, by understanding how this new instrument
is played.

This booklet has been compiled for the purpose of helping you understand the
functions of the YAMAHA SYNTHESIZER, and is to be used together with the
Owners Manual.

The first step to be taken is to set the controls and levers just as they are
illustrated in this booklet and to produce the resultant sounds. Then, the next step
will be for you to freely set the various controls and levers according to your taste.
After a while, you will come to understand the functions of the various controls
and levers as a matter of course.

The captions of the patch examples given in this booklet may differ somewhat
from the image you may have. If this should be the case, adjust the controls until
you obtain the sound that satisfies the image you have in mind. You are given
hundred percent freedom to create sounds that will match image of your own.

Wishing you the best in new music making!

CONTENTS

CS-il] Edition ........................... 3
V/OL /N/TR UMPET/CLAH/ll/ET/SY/V-BASS/
SOUSAPHONE/OBOE/MALE TENOR VO/CE/
FEMALE SUPRA/V0 VOICE/SNOWSTOHM/
SPACE COMEDY THEME/SPACE BETWEEN
CRYSTAL STARS/FL UTE PLA YED BY A
CELEST/AL NYMPH
SOUND MEMO (for your original sound) ....... 9

(IS-30 Edition ........................... 17
HARPSICHORD/STRING ENSEMBLE/BRASS)
BASS/STEAM LOCOMOTIVE/BL UE SKY/
SEOUE/VCER PLUS MELOD Y/WH/STLES OF
THE MIL/(Y WA Y/ACCENTUA TED BASS
SOUND MEMO (for your orig/na/ sound) ....... I5

[IS-30L Edition .......................... 77
P/PE OHGAN/S/TAH/CLARINET
THROUGH FUNK BOX/STEEL DRUM/
PLUS 5TH INTER VAL/LOVE SONG ON THE
TELEPHONE LINE/FLA YFUL PING-PONG
BALL/CRY FROM THE BOTTOM OF THE
EARTH
SOUND MEMO (for your orig/na/ sound) ,,,,,,, 21

NOTE. As the positions of the controls without any
position marks do not affect the tone, they may be left
to wherever they may be.

Since some of the patch examples of C330 and CSGOL
are compatible, try to pair the patch examples up, after
you have come to understand the function of the various
controls and levers.
