Xtant a 3001 6001 owners manual

Page 1

Page 2

Technical Services Our customers satisfaction is our purpose. You represent our present and our future. It is our goal to create and nurture relationships based upon trust and respect. This commitment is not taken lightly or just for today; it is our way of doing business. We believe there is no other way. Xtants policies and procedures are designed, in the event of a problem, to minimize the amount of your down-time and inconvenience. It is our commitment to service and return such product in no more than two (2) working days from the time Xtant receives the equipment. Please consider weekends or holidays (which may fall within the time period) when estimating the return date of serviced product. For technical assistance and information regarding products and/or installation, please contact Xtants Customer Relations Department from 8:00 am to 5:00 pm Monday thru Friday at: Phone: (888) 449-8268 Fax:(602) 431 8600 Welcome Thank you for your purchase of an Xtant amplifier. The concept is simple – a more carefully engineered amplifier will produce superior sound. That is our passion – to exceed your expectation of the automotive llistening experience. We are driven by it. To accomplish this lofty goal, it takes the finest engineering talent in the business, combined with a dedication to superior materials. And we add in a multitude of features, unique cosmetics, and creative system integration. Xtant products are only available through the finest, most highly-specialized mobile audio retailers. Your Xtant Select Dealer was chosen because of their passion for excellence and their commitment to expanding their expertise. Please remember, exceptional audio requires professional installation. Your Xtant Dealer will optimize your system and your level of satisfaction. Whether you are deeply involved in autosound competition, or a privately passionate connoisseur of fine music, we salute you, and appreciate your investment in quality mobile audio. We look forward to a long and lasting relationship! Welcome to Xtant! 2 English Safeguards Please take the time to read this Owners Manual. The following guidelines are designed to assure a safe and properly installed Xtant Mobile Audio System. All Xtant amplifiers and accessories are intended to be installed by a certified pro- fessional mobile audio installation specialist. It is the recommendation of Xtant Technologies that your new Xtant product(s) and all of your mobile audio prod- ucts be installed by your Authorized Xtant Select Dealer. Wiring Requirements All Xtant A Series amplifiers have minimum wire gauge requirements for: Power - 4 gauge Ground - 4 gauge Speaker cables - 12 gauge. Fusing Requirements A Series Amplifiers are not fuse protected! For safety, an outboard fuse may be added close to the amplifier. A fuse must be installed in-line with the power wire at the battery, no further than 18 from battery. For fuse requirements refer to pages 5 and 6 of this manual. In the case of a muti-amp system, use a fuse value equal to the combined value of all (system amplifiers) on-board power fuses. Water and Moisture Install all Xtant amplifiers and accessories in a location free of moisture or exposure to water. 3 English
