Xtant 3300 x owners manual

Page 1

MAXI FUSE 50 AMP MAXI FUSE 50 AMP REMOTE GROUND + 12 V GREEN LED NOISE GATE YELLOW LED LOW IMPEDANCE LEFT RIGHT ORANGE LED THERMAL PROTECTRED LED POWER ON SPEAKER OUTPUTS LEFT LEFT LEFT LEFTLEFT LEFT RIGHT RIGHT RIGHT RIGHT FRONT MONO RIGHT INPUTSFRONT FRONT FRONT XOVR REAR REAR REAR /MONO XOVR OUTPUTS RCA INPUT SELECTOR REAR MONO INPUT SENSITIVITY FRONT INPUT SENSITIVITY PASSIVE ATTENUATION SWITCH –20 –10 0 +10 +20 –20 –10 0 – 8dB – 4dB 0dB +10 +20 + – +POSITIVE – –NEGATIVE + + – –+ + – AMP AMP RCARCA FAN CROSSOVER MODE JUMPERS : FRONT CROSSOVER SIP SOCKETS DEFEAT IN 2 HP 3 LP 1 BYP REMOTESWITCHED 12 VOLTS 16 GAUGE MINIMUM ADD 100 AMP FUSE AT POSITIVE TERMINAL OF THE BATTERY . GROUND – 8 GAUGEMINIMUM POWER – 8 GAUGEMINIMUM BRIDGED OUTPUT BALANCED LINE PORT BALANCED LINE PORT INPUT SENSITIVITY :TO ADJUST INPUT GAIN , MOVE JUMPER (IF NEEDED ) – AND INSTALL IT IN THE LOCATION WHICH MATCHES YOUR INPUT SIGNAL LEVEL . REFER TO THE ILLUSTRATION BELOW FOR PROPER JUMPER LOCATION / LEVEL SETTING . NOTE : –20 dB = 10V – 17V IS ONLY TO BE USED WITH BALANCED INPUT FROM A BALANCED SOURCE . –20 dB = 10V – 17V –10 dB = 3V – 8V 0 dB = 1V – 3V +10 dB = 300mV–1V +20 dB = 100 – 300mV THIS SYMBOL INDICATES THE LOCATION OF THE FOUR (4) MOUNTING HOLES . CROSSOVER FREQUENCY SELECTION : TO CHANGE THE FRE - QUENCY OF EITHER THE HIGH AND /OR LOW PASS FILTERS, REPLACE THE 90 H Z FREQUENCY MODULE(SIP) INSTALLED ON THE CIRCUIT BOARD . NOTE THAT THE IDENTITY OF THE HIGH & LOW PASS SOCKETS ARE MARKED ON THE BOARD . REFER TO THIS DRAWING FOR LOCATION & THE CHART ON THE BACK FOR THE AVAIL - ABLE SELECTION OF SIP/ FREQUENCY VALUES . AMPLIFIER : 3 – L OW PASS 2 – H IGH PASS 1 – BYP ASS RCA OUTPUTS : 3 – L OW PASS 2 – H IGH PASS 1 – BYP ASS HIGH PASS HIGH PASS REAR / MONO AMPLIFIER GAIN CONTROL ROTATE CLOCKWISE TO INCREASE SENSITIVITY . XTANT TECHNOLOGIES 7676 SOUTH 46TH STREET PHOENIX, ARIZONA 85040 PHONE: 602.431.8686 FAX 602.431.8600 LOW PASS LOW PASS INSTALLERS REFERENCE .............. XTANT 3300X.............. Caution: SHARP EDGES be careful when handling top and bottom metal. SPEAKER WIRE – 14 GAUGE MINIMUM RIGHT REAR FRONT REAR / MONO CROSSOVER SIP SOCKETS NOISE GATE THRESHOLD ADJUST :TURN CLOCKWISE TO INCREASE SENSITIVITY NOISE GATE SWITCH :RIGHT POSITION = ON ; LEFT POSITION = OFF ACCESSORY MODULE PORTS FRONT AMPLIFIER GAIN CONTROLS ROTATE CLOCKWISE TO INCREASE SENSITIVITY . REMOVE JUMPERS (2) PRIOR TO INSTALLATION OF ACCESSORY MODULES.JUMPERS MUST BE IN -PLACE WHEN MODULES ARE NOT INSTALLED . 2CHANNEL JUMPER POSITION 4 CHANNEL JUMPER POSITION 2 HP 3 LP 1 BYP 2 HP 3 LP 1 BYP 2 HP 3 LP 1 BYP PASSIVE ATTENUATED
