Page 1
xtant.com Xtant3.1/Xtant6.1 Amplifier Owners Manual WELCOME TO XTANT Congratulations on your Xtant amplifier purchase. The concept is simple-a more carefullyengi- neered amplifier to produce superior sound. That is our passion-to exceed your expectation of the automotive listening experience. We are driven by it. To accomplish this lofty goal, it takes the finest engineering talent in the business, combined with a dedication to superior materials. We add in a multitude of features, unique cosmetics, and creative system integration. Xtant products are only available through the finest, most highly-specialized mobile audio retailers. Your authorized Xtant retailer was chosen because of their passion for excellence and their commit- ment to expanding their expertise. Please remember, exceptional audio requires professional installation. Your Xtant retailer will optimize your system to meet your personal tastes. With your purchase of Xtant mobile audio, you publicly confirm your status as a connoisseur of fine music. We salute you and welcome you to our family. Welcome to Xtant! INSTALLING YOUR XTANT AMPLIFIER All Xtant amplifiers and accessories are intended to be installed by an Xtant-certified professional mobile audio installation specialist. It is the recommendation of Xtant Technologies that your new Xtant product(s) and all of your mobile audio products be installed by your Authorized Xtant retailer. In the event you decide to install your new Xtant product(s), please take the time to read this Owners Manual in its entirety. Installation and/or use of your amplifier in applications or methods other than those specified in your Xtant amplifier owners manual may result in a reduction of the overall performance capability of the amplifier. Any such installation or usage renders the prod- uct warranty void. The following guidelines are designed to assure a safe and properly installed Xtant Mobile Audio System. We strongly recommend that you acquaint yourself with your Xtant amplifiers available features and spend some time designing a system most suitable for you. Consider the components you have now, those you have and plan to upgrade, and those you plan to add in the future. SPECIFICATIONS XTANT3.1 XTANT6.1 Frequency Response: 20 Hz-120 Hz ±1dB 20 Hz-120 Hz ±1dB Number of Channels: 1 1 Watts per Channel @ 4Ω: 1 x 150 1 x 300 Watts per Channel @ 2Ω: 1 x 300 1 x 600 Recommended Load: ≥2Ω≥2Ω Distortion (THD):≤2%≤2% 20 Hz-120 Hz at rated power, all channels driven 4Ω Signal to Noise Ratio:≥100dB≥100dB A-weighted in 20 kHz noise bandwidth @ 1 volt sensitivity Damping Factor:≥100 @ 100 Hz ≥100 @ 100 Hz with 4Ωload with 4Ωload Input Sensitivity: Unbalanced 100 mV-8.5 V RMS 100 mV-8.5 V RMS Balanced 200 mV-17 V RMS 200 mV-17 V RMS Input to Line Output Gain: 0dB 0dB On-Board Crossover: 24dB/Octave Low Pass 24dB/Octave Low Pass Balanced Line: On Board On Board Power Supply: Fully Regulated, PWM Fully Regulated, PWM Operational Voltage: 10-16 Volts 10-16 Volts Fusing Requirement: 40 Amp 80 Amp Size (L x W x H): 11 11⁄16" x 9 1⁄16" x 2" 15 9⁄16"x 91⁄16"x 2 " 297mm x 230mm x 51mm 395mm x 230mm x 51mm Subsonic Filter: 24dB/Octave 20-80 Hz 24dB/Octave 20-80 Hz Bass Boost: 0-12dB @ 45 Hz 0-12dB @ 45 Hz Warranty: Limited 4 Year Parts Limited 4 Year Parts and Labor and Labor 3 FRANÇAIS PG 11 ESPAÑOL PG 19 DEUTSCH PG 27
Page 2
xtant.com CONNECTIONS & CONTROLS 1. INPUT – Xtant3.1 and Xtant6.1 amplifiers feature RCA type input connec- tions. Source units with an output signal level of 100mV–17V may be used. See "Balanced Input" for proper voltage level setting. 2. OUTPUT – These RCA type output connections send full range signals to additional amplifiers eliminating the need for "Y" connectors. 3. BALANCED INPUT – The balanced input switch serves two purposes. First, it helps eliminate noises being induced into the signal path by isolating the sig- nal ground. Second, it is used to set the proper input voltage range: OFF POSITION: 100mV – 8V ON POSITION: 200mV – 17V 4. GAIN – This feature is used to fine-tune the input sensitivity of the amplifier to the source units output level. 5. XOVER FREQUENCY CONTROL – This control allows the user to choose the exact low-pass frequency range the amplifier will play for the best possible performance. The upper end of the crossover frequencies can be selected from 40Hz–120Hz at 24dB per octave. 6. BASS BOOST – This feature will add up to 12dB of low frequency impact to the audio system. The Bass Boost is centered at 45Hz. 7. SUBSONIC – This feature limits the lower end of the low-pass frequencies sent to the subwoofers. The subsonic feature includes a selectable on/off switch, and a control knob used to adjust the lower end of the low-pass range. The subsonic setting can be selected from 20Hz-80Hz at 24dB per octave. 8. RLC – This port allows the use of the optional Xtant remote level control (RLC). The RLC is a bass control module that can be installed in any location within the vehicle for remote adjustments. 9. SPEAKER CONNECTION – Two sets of speaker terminals are provided for dual woofer applications. When connecting a single woofer, use only one set of speaker terminals. WARNING: Xtant3.1 and Xtant6.1 amplifiers are not bridgeable. 10. POWER TERMINALS – This is the main power connection for the ampli- fier. The power and ground wire size should be the same gauge. GND – The ground wire from this connection must be attached to bare metal on the vehicle. REM – To turn the amplifier on/off, this terminal must be connected to the source units "remote or electric antenna" wire. +12V – The power wire from this connection must be attached to an inline fuse, then to the positive side of the vehicle battery. WARNING: An outboard fuse must be installed in-line with the power wire within 18 inches of the battery. 5 Xtant3.1/Xtant6.1 Amplifier Owners Manual PERFORMANCE FEATURES SUBSONIC FILTERThe subsonic filter maximizes your Xtant amplifiers output when a specifically tuned subwoofer system is used. FULLY REGULATED PWM POWER SUPPLYXtant amplifiers feature a Fully Regulated, Pulse Width Modulated power supply. This power supply technology provides high efficiency and consistent output performance even when battery voltage is less than optimum. CROSSOVER This control allows the user to choose the exact low-pass frequency range the amplifier will play for the best possible performance. BALANCED/FLOATING INPUT When enabled, this circuitry helps to eliminate system noise associated with ground loops. When combined with the input sensitivity adjustment, it allows the amplifier to accept up to 17V of input signal. PROTECTION CIRCUITRY Both Thermal and Overcurrent protection are incorporated into Xtant amplifiers. In the event of a problem, the amplifier will reduce its power to maintain operation. STATUS LEDS (LOCATED ON THE TOP OF THE AMPLIFIER)Three LEDs indicate operational status of Xtant amplifiers. The red LED illuminates when the amplifier is ON, the yellow LED indicates that overcurrent protection is engaged, the orange LED indicates that the thermal protection circuit is engaged. OPTIONAL PERFORMANCE ENHANCEMENTS HIGH LEVEL ADAPTER (HLA)High Level Adapters allow you to connect a source unit with speaker level outputs to your Xtant amplifier. REMOTE LEVEL CONTROL (RLC)The RLC or Remote Level Control allows a bass control to be adjusted remotely from the drivers seat. 10 9 8 7 6 5 4 3 1 2
