R200 R Series Mixers

Thank you for purchasing an R Series Mixer from Wharfedale Professional. Please read these
instructions carefully to ensure problem free operation and user satisfaction. The R Series of mixers
from Wharfedale Professional are designed to offer a superior quality audio performance in an easy
to use, great value package. The quality of the R Series is such it can be used in a variety of

professional applications such as studio, sound reinforcement, field recording and film/video
production.

Features R200:

*

4 balanced/unbalanced mono line inputs
4 low noise, high headroom XLR mic inputs

2 pairs of balanced/unbalanced stereo line input with +4/-10
input gain/sensitivity selector

48V phantom power

* 3 band E0 in each input channel (12kHz, 2.5kHz, 80Hz)

75Hz, 18dB/octave low cut filter on channels 1-4

* EFX to AUX switch

Peak LEDs on mono channel

One aux send and one effect send

Separate main mix, control room and headphone outputs

2 track inputs assignable to main mix, control room/headphone outputs
Highly accurate 4 segment bargraph meters

High quality 60mm fader on master output

* 19 Rack Mounting kit included

Getting Started
Power Supply

The R Series mixer is supplied with an external power supply unit. Only use the power supply provided with
your mixer. Connect the R Series mixer to the power supply unit and THEN connect the power supply unit to
the Mains. During long periods of operation the mixer may become warm. Therefore it is important that the

' , unit is placed where the air is able to flow freely around it.

Packing

Every care has been taken to ensure that your mixer reaches you in perfect condition and working order. The
exterior and internal packaging has been designed to protect the unit in transit, but should you notice any
damage to the unit, please notify the place of purchase immediately.

Warranty

The R Series mixers warranty covers any defects in the manufacture of the product for a period of 12 months
from the date of purchase. The Warranty is nontransferable and applies to the original purchaser only.

Should you have any Warranty issues, please contact your place of purchase who will advise on a returns
procedure.
