Extracted text from Toshiba SA V10 Service Manual (Ocr-read)
Page 2
SK-V10
1. OPERATING CONTROLS
G) @963 ® ®
Figure 1
Figure 2
To AC outlet
Speaker SAVVTO Speaker
PC~V10
Ground connection
One-touch connection cord
Ou tpu t
cords C
Power cord
Turntable
control
cord
Turntable
control
terminal
SR-V10 Tu rntable
Figure 3
CAUTION: Before returning the unit to the customer, check that the resistance between both blades of AC plug
and any accessible metal parts is more than 3M9. after completion of servicing, using the circuit testert
(TA Model only)
Page 7
SK-V 10
3. MOUNTING OF MECHANISM PARTS
MOTOR GEAR MOUNTING POSITION
1. When mounting gear to motor shaft, press the gear until it is flush with top of the motor shaft.
Motor Shaft Motor Shaft
mm]: fl [HE Aw
lll III]
Chassis Chassis
Assist Motor Reel Motor
Figure 22 Figure 23
BELT THREADING
1. First thread the belt around the flywheel and then temporarily secure the belt to the protruding part of chassis. Mount
the motor and motor mounting plate. Remove the belt from the protruding part and thread it to the motor pulley.
Motor Pulley
Protruding part ,
Main Chassis
Flywheel
Figure 24
POSITIONS OF REEL MOTOR AND ASSIST MOTOR
1. Make sure (lumarks are positioned as illustrated.
Motor Mount
Figure 25
Figu re 26
