Toa wt 4820
This is the 6 pages manual for toa wt 4820.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from toa wt 4820 (Ocr-read)
Page 1
WM - 4310H UHF Headset Wireless Microphone WM-4200 UHF Handheld (Vocal) Wireless Microphone WM-4210 UHF Handheld (Vocal) Wireless Microphone WM-4220UHF Handheld (Speech) Wireless Microphone WM - 4300 UHF Lavaliere Wireless Microphone WM - 4310 UHF Lavaliere Wireless Microphone -Operating range : 3m-150m -Dynamic cardioid microphone element designed for vocal use -Four 16-channel banks of circuit frequencies -Input sensitivity control included -Maximum input level : 145 dB SPL -Dynamic range: over 110 dB -Rubber coating minimizes handling noise. -ON/OFF switch designed to prevent accidental activation -LED low battery indicator-Operating range: 3m-120m -Dynamic cardioid microphone element designed for vocal use -16 selectable channel frequencies -Maximum input level:130 dB SPL -Dynamic range: over 110dB -On/Off switch also keeps mic from rolling when put down -Flashing LED low battery indicator-Operating range : 3m-120m -Electret condenser cardioid microphone element for speech use -16 selectable channel frequencies. -Maximum input level : 125 dB SPL -Dynamic range: over100dB -On/Off switch also keeps mic from rolling when putdown -Flashing LED low battery indicator -Operating range: 3m-150m -Electret condenser cardioid microphone element for speech use -Four 16-channel banks of circuit frequencies -Input sensitivity control included -Maximum input level: 120 dB SPL -Built-in circuitry designed to minimize the influence from ambient noise -Belt clip rotatable 360 degrees -Highly reliable TA-4 mini-cannon microphone plug -Flashing LED low battery indicator-Operating range : 3m-120m -Electret condenser cardioid microphone element for speech use -16 selectable channel frequencies -Input sensitivity control included -Maximum input level : 120 dB SPL -Built-in circuitry designed to minimize the influence from ambient noise -Belt clip rotatable 360 degrees -Locking mini-plug microphone jack -Flashing LED low battery indicator -Operating range : 3m-120m -Electret condenser cardioid microphone element for speech use -16 selectable channel frequencies -Input sensitivity control included -Maximum input level : 120 dB SPL -Built-in circuitry designed to minimize the influence from ambient noise -Belt clip rotatable 360 degrees -Lock-equipped mini-plug microphone jack -Flashing LED low battery indicator -Headset provides secure and comfortable fit on head Wireless Microphone Units TOA has improved on Phase Locked Loop (PLL) synthesis technology for use in its wireless microphone systems, virtually eliminating any frequency oscillation that can sometimes occur with variations in ambient temperatures. TOA, s new line of wireless microphones comprises handheld models WM-4200, WM-4210, and WM-4220, lavaliere models WM-4300 and WM-4310, the WM-4310H headset model and the WM-4310A with a dedicated headset for aerobics and other active applications. -Up to 16 microphones can be used in the same area without any problems. -A wide operating range allows microphones to be used up to a maximum of 150 meters distance (WM-4200 and WM-4300) from the tuner units. -Extended battery life: provides over10 hours of continuous use at average temperatures - Adjustable input sensitivity for precise control of input prevents distortion and overloading. A full range of components for configuring an ideal wire
Page 2
-16 selectable channel frequencies -Auto mixing input function -Tone squelch function -TOA Space Diversity technology* -Rod antenna x 2 -Squelch function (Carrier, Noise) -Balanced output (XLR connector) and phone jack output -Microphone sensitivity adjustment function WM-4310A UHF Headset (Aerobics) Wireless Microphone WT-4800UHF Wireless Tuner -Operating range: 3m-120m. -Electret condenser cardioid microphone element for speech use. -16 selectable channel frequencies. -Input sensitivity control included. -Maximum input level: 120 dB SPL. -Built-in circuitry designed to minimize the influence from ambient noise. -Belt clip rotatable 360 degrees. -Lock-equipped mini-plug microphone jack. -Flashing LED low battery indicator. -Headset securely and comfortable fits on head. -Sweat-resistant headset microphone. -Securely fitting belt with pouch. Tuner Units WT-4810 UHF Wireless Portable Tuner All TOA wireless microphone tuners utilize the Phased Lock Loop (PLL) synthesis method to deliver exceptional performance along with stability and reliability, minimizing oscillation frequency variations caused by ambient temperature variations. In addition, overall performance is enhanced by the TOA Space Diversity circuitry and antenna diversity technology that is also incorporated in these units. The tuner units comprise the WT-4800 and WT-4810 1-station units, models, the WT-4820 2-station unit and the WTU-4800 tuner unit for mounting on the WT-4820 unit. The WT-4800 provides 64 selectable frequencies, the WT-4810 and WT-4820 16 selectable frequencies. -TOA's proprietary Space Diversity technology and algorithm are incorporated in each tuner to provide constant area coverage. Total performance and reliability are also enhanced through TOA's simpler and more effective circuitry compared to conventional diversity tuners. -Four 16-channel banks of circuit frequencies -Antenna cascade output function (parallel connection possible for linking three WT-4800 units) -Auto mixing input function -Tone squelch function -TOA Space Diversity technology* -Usable frequencies scanning channel check function -1/4 wave antenna x 2 -Compact 19" rack-mount design -Microphone sensitivity adjustment function -Compander circuit for minimizing ambient noise less s ystem.
