INSTRUCTION MANUAL

WM-5220

Thank you for purchasing TOA's UHF Wireless Microphone.
Please carefully follow the instructions in this manual to ensure long, troublerfree use of your equipment.

1. SAFETY PRECAUTIONS

~ Be sure to read the instructions in this section carefully before use.
~ Make sure to observe the instructions in this manual as the conventions of safety symbols and messages

regarded as very important precautions are included.

- We also recommend you keep this instruction manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and properly
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

AWARNING
A CAUTION

Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.

Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or properly damage.

A WARNING

- To prevent the electromagnetic wave from badly
influencing medical equipment, make sure to
switch off the unit's power when placing it in close
proximity to the medical equipment.

A CAUTION

- When the unit is not in use for 10 days or more, be
sure to take the battery out of the unit because
battery leakage may cause personal injury or
contamination of environment.

- Make sure to observe the following handling
precautions so that a fire or personal injury does
not result from leakage or explosion of the battery.

~ Do not short, disassemble, heat nor put the
battery into a fire.

4 Never charge batteries of the type which are not
rechargeable.

, Do not solder a battery directly.

~ Be sure to use the specified type of battery.

~ Note correct polarity (positive and negative
orientation) when inserting a battery in the unit.

4 Avoid locations exposed to the direct sunlight,
high temperature and high humidity when storing
batteries.

CAUTION T0 USER: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
the equipment.

TOA Corporation

Page 2

2. GENERAL DESCRIPTION

The TOAs WM-5220 Wireless Microphone employs an electret condenser microphone element of high
sensitivity and intelligible sound quality, and is suitable for speech use.

3. FEATURES

- One frequency can be selected from 16 operating frequencies 01 692 7 865 MHz.

- An optimized PLL»synthesizer minimizes the oscillation frequency drilt resulting Irom the ambient
temperature or voltage fluctuation.

- Power/Battery lamps indicate battery consumption to prevent the unit from malfunctioning when the battery
level remarkably decreases.

- Operates on a single AA battery.

- Employs a built-in antenna.

- The state of battery consumption can be displayed on the tuner's indicator when the unit is used in
conjunction with the optional WT-5800, WT~5805 or WT-5810 Wireless Tuner.

4. HANDLING PRECAUTIONS

- Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as
doing so may result in unit failure.

- Never open nor remove the unit case to modify the unit. Reter all servicing to your nearest TOA dealer.
- Take care not to drop the unit onto the floor nor bump it against a hard object as the unit could tail.

- Do not place the unit in locations of high temperature (ex. in a car parked in summer) or high humidity as the
unit could tail.

- Do not use the unit in locations where it is exposed to seawater.

- To clean, use a dry cloth. When the unit gets very dirty, wipe lightly with a cloth damped in a dilute neutral
cleanser, then wipe with a dry cloth. Never use benzine, thinner, or chemically-treated cleaning towel.

- Avoid using a mobile telephone near the wireless microphone in use. Noise could be picked up.

- When using two or more wireless microphones, keep them at least 50 cm away from each other to avoid
malfunctions or noise.

- Keep the wireless microphone at least 3 m away from the receiving antenna. Using the microphone in close
proximity to the antenna could result in malfunctions or noise.

5. NOMENCLATURE

(HANVEL
Power/Battery lamps e7 ' t
~ A green LED lights as long as the battery
capaclty ls sulficlent.

When the battery capaclty becomes low, the
green LED starts to dlm, Whlle the red LED IO
light.

The microphone does not transmit the signal it
the channel selector swttch IS set to the empty
channel. In this case, the red LED and green
LED Ilash alternately.

Channel select switch

1

New Emphasis circuit ON/OFF switch
H: ON L: OFF
' Enables further noise suppresslon
(Valid only ter WT-5800 series
Wireless Tuners)

I

Power ON/OFF switch 4

6. BATTERY INSERTION

Step 1. Turn oh the power switch.

Step 2. Hold the microphone body and rotate the microphone
grip counterclockwise to remove it.

Step3. Insert an AA battery according to (+) and (,)
indications on the battery compartment.

Step 4. Replace the microphone grip by sliding and rotating it
clockwise.

Battery replacement

- A brand-new AA alkaline battery will continuously operate the unit for
about 10 hours.

- When the battery capacity becomes low, the green LED ot the
Power/Battery lamps starts to dim, while the red LED to light.
When only the red LED lights, replace the battery with a new one. In this
condition, the unit transmits the remaining battery capacity information to
the tuner, causing the tuners BATT indicator to light.

Red LED Green LED

7. CHANNEL NUMBER SETTING

Step1. Switch oh the power. Rotate the microphone grip
counterclockwise to remove it. CHANNEL

Step 2. Using the supplied screwdriver, set the Channel setting .
switch pointer to the desired channel number.

Step 3. Replace the microphone grip.

Note: Make sure that the wireless microphone is identical to
the wireless tuner in the channel number. Should the
microphones setting difler trom that of the tuner, the
tuner does not receive the microphone signal.

8. OPERATION

Step 1. Confirm that the wireless microphone and the wireless tuner are identical in the channel number. If
not identical, turn the power ONIOFF switch to the OFF position, then set the channel number to the
same channel number as the tuner.

Step 2. Turn the Power ON/OFF switch to the ON position. Then, confirm the green LED of the Power/Battery
lamps will light.

Step 3. Turn the Power ON/OFF switch to the OFF position after use.

9. OPERATIONAL HINTS

- The microphone's service distance is 3 , 120 m. When the microphone user moves in a facility, signal
dropouts (momentary losses of signal reception) may be encountered. These dropouts are caused by the
buildings architectural designs or materials which block the travel of or reflect the radio signal. It this occurs,
the user needs to change locations for better signal reception.

- The proper operation of your wireless system may be interfered with by other system operating on the same
frequency. In such cases, change the operating frequency of your system. (As to dealing with the
interference, refer to the operating instructions of the wireless tuner.)

- Should you have any questions regarding the use or availability of TOA wireless products, please contact
your local TOA dealer.
