Page 1
-I L\|
O! VIVI-3000 SERIES
INTEGRATED VOICE
EVACUATION SYSTEM
Emergency Vaiee Alarm System
Incorporating Digital Audio PA, Paging and BGIVI
Page 1
-I L\|
O! VIVI-3000 SERIES
INTEGRATED VOICE
EVACUATION SYSTEM
Emergency Vaiee Alarm System
Incorporating Digital Audio PA, Paging and BGIVI
Page 2
High-quality, compact public address system
also features safety-enhancing emergency e
l _ v . 7 My. . :71. ; _ \kfiw. a. 2:4
O Max. 4 MIC/LINE inputs
O 2 BGM inputs
O Up to 4 Fireman's/Remote Microphones connectable
(max. 2 Fireman's Microphones)
O Max. 60 assignable speaker zone outputs
(6 zones per amplifier)
O Volume setting possible for each zone
O Digital audio processed & controlled
- Full digital audio mixing (DSP)
- Built-in high quality electronic voice message
O Intuitive configuration
. Zone setting, priority setting, failure detection setting by
dedicated PC software
- LCD display of current status and configuration setting of
system units.
O Cont uous speaker line monitoring without
interruption of BGM distribution or paging
announcements
O Complete fault detection and indication
O Off-site log check capability via LAN
O Both built-in and remote Fireman's Microphones
O Built-in voice alarm message
O 2-Phased voice alarm message (Alert and
Evacuation) broadcasting
O 2 Remote Microphone interface lines
O Paging (All zones/Group/lndividual)
O 2-channel broadcast with external amplifier
(Paging/BGM)
a
a
a
o
q
o
o
1
e
o
o
o
o
a
o
a
o
.
