1. GENERAL DESCRIPTION

The 8-208 is an electronic Sound Repeater module to be used in conjunction with the A-900 series, BG-1000
series amplifies, and VX-2000.

Four types of audio sources such as music and messages (3 minutes total time) can be recorded and played
back.

The USB port facilitates recording by transferring audio sources from a PC to the module.

2. FEATURES

- Supplied software permits audio files to be easily transferred from a PC to the Sound Repeater over a USB
connection.

- Provides high quality of sound because audio data is not compressed when recorded.
- Playback and stop operations can be remotely controlled from external equipment.
- Repeat playback is enabled when playback intervals are set with the supplied software program.
