Enjoy the advantages of using IP networks

The NX-100 Network Audio Adapter satisfies the requirements for transmitting
high quality audio signals and control signal as serial data over networks using
the IP protocol in real time.These include the internet and LANs and allow
significant cost reductions when transmitting audio signals to various

remote areas as costly dedicated lines do not have to be used.

- If there is no network delay, audio signals have only a - Using IP to transmit audio signals over the internet allows low
minimal millisecond delay. cost operation rather than dedicated lines.

- Control data including contact and serial data can also be - The NX-100 is equipped with a DC input to allow operation on
transmitted along with the audio signals. AC as well as DC.

. Two-way audio signal transmission is possible with a single - Software-driven operational menus enhance ease of use.
NX-1OO unit as every unit is equipped with an audio input and

output.

- The multicast-capable NX-100 allows simultaneous
transmission of audio signals to be made to multiple
locations depending on transmission method:

Unicast - up to 4 locations,
Multicast - up to 64 ocations.

- No audio signal degradation or loss, even when
transmitting over crowded networks such as the internet.

- Greater data reliability using IP networks with the protocol's
ability to prevent data problems during transmission.

- The NX-l 00's contact input can initiate and terminate
audio transmissions without having to use dedicated
control equipment such as a PC.

- Hardware use ensures operational reliability over only
software-driven applications.

Remote Multi-Point Access Broadcast System Base
l/V \\
% Headquarters
Sound sour-c; H Dedicated
line 2 ..... . ............. . Router
..._ . . -
o a a so a a e , . f
equipment U 2 :dtcated it} C} Q 9322 it 5} o
fiEfi-hifi a a: {2 Amplifier U Speaker
ESSEBEEQQ a k.
[! PC Branch office
i
Router Internet 3
a... l Amplifier
Setting/operation C} C} b 5'9} f3 5:2 -1
software
Modem
supplied with the NX-100 D orAlSSglhl - router
S eaker
R J D J
