E TOA
Top View
IDESCRTPTTON
STANDARD MASTER STATION
N-8010MS(Y)
This Master Station is designed to connect to the 1P Intercom Exchange, and provides handsifree
or handset conversation of high sound quaiity This station can be mounted to the wait using an
optionai YC-ZSO wall mounting bracket:
ISPECTFICATIONS
*OdeiV
Power Source
48 V DC (suppiied from the 1P intercom exchange (option))
Power Consumption
1.8 W
(at rated), 2.4 W (max)
Wiring Method
Non-poiar one pair stranded wire system
Transmission System
2 wire (60 kbps echo canceiier transmission system
Signai Levei
Under
0 dB*
Speech Method
Handsifree or handset conversation
Audio Frequency Range
300 - 7000 Hz
Transmission Range
Max.
i500 m (@065 mm, Loop resistance (70 Q)
Send path: Eiectret condenser microphone
Hands-tree Speaker: 57 cm cone-type, 0.6W, 8 Q
Microphone: Omniidirectionai eiectret condenser microphone
Handset Receive path: Cone-type
Line Connecting Terminai
RJi i moduiar iack
instaiiation Method
Desk/Surface mounted master station
(When
mounting to the wait,
use the optionai YC-280t)
Operating Temperature
O'C to +40"C
Operating Humidity
Under 90% RH (no condensation)
Finish Body, Handset: ABS resin, gra
Dimensions 148 (W) x 208 (H) x 705 (D) mm (exciuding a curl cord section)
Weight 700 g
Accessory Connection cord (3 m)~1
Option Waii mounting bracket: YC7280
IAPPEARANCE
Front View
SCALE: 1/3
UNITrrnm
0
Side View
.486
207. 3
MT
Figure of the
desktop instaiiation
(scaie: 1/5)
Rear View
04K
TOA Corporation
DWG No: GN-OODAl-S
