Page 1
H I DA
A OPERATING INSTRUCTIONS
SPEAKER SYSTEMS
F-13OOB F-1300W
F-13OOBT F-1300WT
F-13OOBTWP F-1300WTWP
Thank you for purchasing TOAs Speaker System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TOA Corporation 5330648130
Page 1
H I DA
A OPERATING INSTRUCTIONS
SPEAKER SYSTEMS
F-13OOB F-1300W
F-13OOBT F-1300WT
F-13OOBTWP F-1300WTWP
Thank you for purchasing TOAs Speaker System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TOA Corporation 5330648130
Page 2
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ................................................................................. 3
2. GENERAL DESCRIPTION .............................................................................. 4
3. FEATURES ........................................................................................................... 4
4. DIMENSIONAL DIAGRAM .............................................................................. 4
5. IMPEDANCE CHANGE
(F-1300BT, F-1SOOBTWP, F-1300WT, and F-1300WTWP only) ............................... 5
6. ABOUT THE INPUT OVERLOAD PROTECTION CIRCUITRY
(F-1SOOB and F-1300W only) .................................................................................... 5
7. NOTES ON OUTDOOR INSTALLATION
(F-1300BTWP and F-1300WTWP only) .................................................................... 6
8. INSTALLATION
8.1. Using the Supplied Brackets
8.1.1. When using only the supplied brackets ................................................... 7
8.1.2. When using both the supplied and optional mounting brackets ............... 7
8.2. Speaker Cable Connections .......................................................................... 7
83. Wall Mounting .................... 8
8.4. Ceiling Mounting ........ . 10
8.5. Speaker Stand Mounting 12
8.6. Pole Mounting (F-1SOOBTWP and F-1300WTWP only) ................................... 13
8.7. Partition Board Mounting
(F-1SOOB, F-1SOOBT, F-1300W, and F-1300WT only) ..................................... 14
9. REPAINTING THE SPEAKER ...................................................................... 15
10. SPECIFICATIONS
10.1. F-1SOOB and F-1300W ................................................................................... 16
10.2. F-1SOOBT and F-1300WT .
10.3. F-1300BTWP and F-1300WTWP ................................................................... 18
