SPECIFICATIONS CA-200, CA-400DN & CA-600DN MOBILE AMPLIFIERS PERFORMANCE Frequency Response 100 Hz - 10 kHz Total Harmonic Distortion < 5% at rated output Noise Floor (below rated output): CA-200 > -74 dB (controls at min) > -64 dB (controls at max) CA-400DN > -82 dB (controls at min) > -65 dB (controls at max) CA-600DN > -83 dB (controls at min) > -66 dB (controls at max) INPUTS/OUTPUTS Inputs (sensitivity / impedance) Mic 1 & 2 4 mV / 600 ohms Auxiliary 500 mV / 10 k ohms Outputs (output/load): CA-20020 W / 4 ohms, 10 W / 8 ohms CA-400DN 40 W / 4 or 8 ohms CA-600DN60 W / 4 or 8 ohms FUNCTIONS Input Volume Controls Mic 1 and 2 Power Push-on / push-off switch Input Jacks 1/4" for Mic 1, 2 and aux line (accepts tip/sleeve 1/4" jacks) Indicator Power on LED PHYSICAL Enclosure: CA-200 Black front panel, painted steel chassis CA-400DN & CA-600DN Black front panel, anodized steel chassis Dimensions (W" x H" x D") CA-200 4.72 x 2.36 x 6.69 CA-400DN & CA-600DN 7.00 x 1.97 x 7.15 Power requirements (at rated output): CA-200 10 V - 16 V DC. 2.8 A CA-400DN 10 V - 16 V DC. 5.5 A CA-600DN 10 V - 16 V DC. 9.0 A Weight (lbs) CA-200 1.5 CA-400DN 3.1 CA-600DN 4.0 All specifications are subject to change without notice. APPLICATIONS uConstruction vehicles. uLaw enforcement vehicles. uFire and other emergency vehicles. uBoats. uBattery powered emergency back- up for paging systems. FEATURES uCompact, elegantly styled, 12V DC amplifiers for public address use. uThree models in 20, 40 and 60 Watts. uTwo microphone inputs with sepa- rate volume controls. uUni-directional microphone with on/off switch included with each model. uAuxiliary/line input for connecting tape player, radio or portable CD. uCA-400DN and CA-600DN are DIN standard size to fit dashboard or console radio slots. uMounting brackets, hardware and wiring are included with each model. THE TOA ADVANTAGE uNumber one choice of sound con- tractors for eight years running. uTwo-year, no questions asked prod- uct warranty. uSame day shipment on most orders. uDelivering rugged and innovative products worldwide for more than 60 years. 601 Gateway Blvd., Suite 300 South San Francisco, CA 94118 Phone: (415) 588-2538 Fax: (415) 588-3349
