Technics SU 9200 Owners Manual

Page 1

ITechnics

STEREO CONTROL CENTER

SU-SEDO

Before operating this set. please read these instructions completely.

Page 2

STEREO CONTROL CENTER SU-QEOO

I

Thank you for selecting the "Technics" model
SU-9200 pre-amplifier.

The model SU-9200 is the result of the combined
efforts of Technics engineers who have de-
voted many long years of research to improving
the efficiency and sound reproduction of audio
equipment.

Only the highest quality products have been used
for even the smallest components, and each unit
is designed so as to assure maximum reliability
and high quality performance.

In order to assure that you will receive maximum
benefit from the many features of this unit, we
urge you carefully read and follow the operating
instructions in this booklet.

CONTENTS

HELPFUL HINTS ....................................... 1

STAR FEATURES ....................................... 2

CONNECTION WIRING FOR A

STEREO SYSTEM ................................. 3

CONTROLS AND THEIR FUNCTIONS ............ 4

CONNECTIONS AND OPERATION ............... 7
POWER AMPLIFIER CONNECTIONS AND
OPERATION .......................................... 7
RECORD PLAYER CONNECTIONS AND
OPERATION .......................................... 7

TUNER CONNECTIONS AND OPERATION 8
CONNECTIONS TO THE AUXILIARY INPUT

TERMINALS AND OPERATION .................. 8
TAPE DECK CONNECTIONS, RECORDING
AND PLAYBACK .................................... 9
GROUND CONNECTION ....................... 10
AC OUTLETS .................................... 10
OPERATION CAUTIONS .............................. 11
BLOCK DIAGRAM .................................... 12
RESPONSE CURVES ................................. 13

TECHNICAL SPECIFICATIONS ..................... 14

HELPFUL HINTS

1. Keep this unit away from electrical noise-generating
devices such as motors and fluorescent lamps.

2. The set should not be exposed to direct sunlight and
should be kept free from dust, moisture and vibration.

3. The cabinet of this unit should be given the same care
which you would give any piece of fine furniture. The
front panel should be cleaned with a soft cloth moistened
with a mild soap-and-water solution.
NEVER USE A SOLUTION CONTAINING BENZOL OR
PETROLEUM.
