Page 15
ORDER NO. SD7801-1258-2
S rvice Manual
Stereo Flat Preamplifier
SU-907O
Improvement of Abnormal Oscillation at MM Terminals
Notes: * This service manual includes only the changes of the SU-9070 service manual
(ORDER NO. 8077084258),
* When servicing model SU-9070, this service manual and SU-9070
(ORDER NO. 8077084258) service manuals should be used togther |
l REPLACEMENT PARTS LIST
R61 No Old i New
' ' Part No. # Part No. Part Name & Description Per Set Remarks
R2514252 ERDZSTJlSO ERDZSTJ68O Carbon 6894 1/4W, 15% 1
C223224 ECCD2H33OK ECCDZHGSOK Ceramic, 68pF, 500V, :10% 1
I SCHEMATIC DIAGRAM
o Equalizer Circuitry
R251,252
Technics Matsushita Electric Trading Co., Ltd.
PO; Box 288, Central Osaka Japan
Printed in Japan
7801-7450 ®
