Technics SLS 138 Service Manual

Page 1

ORDER NO. A09603079A2

Service Manual

multi-slnge noise shaping

coMpAcT MAS H %
35$

DIGITAL AUDIO

Portable CD Player

SL-8138

Colour
(K)...Black Type

Areas
Suffix for
Model No. Area Colour
(E) Europe. (K)

>1<~ o MASH is a trademark of NTT.

L

Please file and use this manual together with the service manual for Model No. SL-XP140, Order No. AD9603057CB. ]

Note: I This simplified service manual is provided to indicate the main differences between the original model No. SL-XP140 (E)
and the subsequent model Nor SL-Si 38 (E).

CHANGES

.CHANGE IN REPLACEMENT PARTS LIST (SL-XP140 Service Manual of pages 30, 31.)

Notes: 0 Mentioned in this parts list is only those different from Model No. SL-XPi 40 (E).
All other parts are the same as for SL-XP14O (E).

Change of Part No. . .
Ref. No. Part Name & Description Remarks
SL-XP140 (E) # SL-S138 (E)
CABINET AND CHASSIS
5 RFKJLXPMOEK RFKJL81 38E-K BOTTOM CABINET ASSY
7 RYF04220-K RYF0422B-K CD COVER ASSY
PACKING MATERIAL
P1 FIPK0739 RPK074O PACKING CASE
P2 RPQOSSO RPQOGSS SPACER
P5 SQZDS - - Deletion
ACCESSORIES
A1 RFKSLXP140EK RFKSLSlSBE-K INSTRUCTION MANUAL ASSY
A2 RFEA401 E-ZS - - Deletion
A5 RFEV317A-KS RFEV317P-KS STEREO EARPHONES

, A WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public. it
does not contain warnings or cautions to advise non»technica| individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
