ORDER NO. AD980100580
A6

a vice Manual

6W? Compact Disc Changer S L- P D349
8 L- P D 6 65

I This document is supplementary to the S L- P D 6 8 7

following Service Manuals:

Model No. Area Code Order No. S L- P D 8 8 7
SL-PD349 (P) AD9404110A1
SL-PD665 (PP) AD9401023A1 Colour (K) B'a°k Type
SL-PD687 (E) (EB) (EG) (GC) (GN) AD950204308 Areas
.. U.S.A.
E E
SL-PD887 ( ) ( B) (EG) A09502066A2 USA. and Canada.
(GC) (GN) A09502067A3 .. Europe.
..Great Britain.
I Purpose ..Germany and Italy.

Please be informed of that the Traverse Deck (Assy)" and CD Servo 60' AA/li'ji'leirenafgifa
P.C.B." of the CD unit have been changed on production. and Africa.
. . . GN .............. Oceania.
I Appllcable Serial Number Suffix
Model No. SL-PDS49 SL-PDSSS SL-PD687 SL-PD887

Serial No. Suffix from K " onward from I "onward from F " onward from F " onward

I How to distinguish in CD unit on unit

CD servo P.C.B.

CU7... is shown in this place
of CD servo P.C.B.

I interchangeability
The NEW" Traverse Deck (Assy) (RAEO152Z) and the FORMER Traverse Deck (Assy) are interchangeable.
Even if the CD unit has the former servo P.C.B., only the traverse deck is changeable to the new one.

A WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It
does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
