Technics SLMC 70 Service Manual

Page 1

ORDER NO. MD9802039A1

Service Manual

[flfigfi m M ASH" Compact Disc Changer

mvitl me noise mom
DIGITAL AUDIO

Colour
(K) . Black Type
Area

Suffix for
Model No. Area Colour

(P) u.s.A.

(K)
(PC) Canada

* .
RAEOISZZ-M TRAVERSE DECK SERIES MASH '3 *1 "ademark 0 N-
L Please file and use this manual together with the service manual to Model No. SL-MCSO(P/PC), Order No : AD951024501. J

Note : 0 This simplified service manual is provided to indicate the main differences between the original model no. SL-MC50 (P/PC)
and the subsequent model no. SL-MC7O (P/PC) respectively.

I Change In Replacement Parts List
Notes: - Important safety notice:

Components identified by 1". mark have special characteristics important for safety.
Furthermore. special parts which have purposes of fire-retardant(resistors). high-quality sound(capacitors), Icw noise(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer's specified parts shown in the parts list .
- [M] Indicates in the Remarks columns indicates parts supplied by MESA.
- The parenthesized indications in the Remarks columns specify the areas.(Refer to the cover page for area)
Parts without these indications can be used for all areas.

Change of Parts Number
Ref. No. Description SLIM,C5O (P/PC) SL-M C70 (PIP 0) Remarks
(Original)

CABINET AND CHASSIS

1 CABINET ASSEMBLY FIKM0314-K RKMOBSG-K [M] CHANGED

4 CONNECTOR ASSEMBLY(6P) REX0810-1 - [M] DELETED

5 CORD HOLDER SHRD162 - [M] DELETED

6 32F FCC RE20828 FIEE0823 [M] CHANGED

B REAR PLATE RGR0231A-A1 RGR0247A-WA [M] CHANGED (P)

8 REAR PLATE FIGR0231A-B FIGR0247A-XA [M] CHANGED (PC)

9 CHASSIS ASS'Y RFKJLMCEOP-K FtFKJLMC70P-K [M] CHANGED

9-1 LEG RKAOOSS-A RKA0079»A [M] CHANGED

21 14P FCC RE20830 REE0830 [M] CHANGED

22 FRONT PANEL ASSEMBLY RFKGLMCSOP-K RFKGLMC70P-K [M] CHANGED

25 SCREW RHD26024-T RHD26028-T [M] CHANGED

28 MECHA ANGLE RMA0918 RMA099B [M] CHANGED

A WARNING
This service information is designed for experiense repair technicians only and is not designed for use by the general public. It does not contain
warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity
should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product or products dealt with
in this service information by anyone else could result in serious injury or death.
(9 1998 Matsushita Electronics (S) Pte. Ltd.
. ® All rights reserved. Unauthorized copying and
ec nlcs distribution is a violation or law.
