Technics SLB 202 Service Manual
This is the 17 pages manual for Technics SLB 202 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Technics SLB 202 Service Manual (Ocr-read)
Page 1
ORDER NO. SD81061954C3:
Service Manual
Turntable System
SL-BZOZ
lEl,lEKl.[XLl,lEGl,[EBl.lEHl,
[EF],[Ei],[EA],[EC],[XA],[XM]
SL-8202(K)
lE],[EKLlXLllEGllEBilEH],
[EF],[Ei],[EA],[EC],[XA],[XM]
Areas
* [E] is available in Switzerland and Scandinavia.
* [EK] is available in United Kingdom.
* [XL] is available in Australia.
* [E6] is available in F.R. Germany
* [EB] is available in Belgium.
* [EH] is available in Holland
[EF] is available in France.
" [Ei] is available in Italy.
' [EA] is available in Austria.
[EC] is available in Czechoslovakia
* [XA] is available in Southeast Asia, Oceania, Africa,
Middle Near East and Central South America.
(a The colors of this model include silver and black.
* The black type model is provided with (K) in the
¥ Service Manual.
I Turntable section
Type:
Drive method:
Motor:
Drive control method:
Turntable platter:
Turntable speeds:
Pitch control:
Automatic turntable
Auto return
Auto stop
Belt drive
DC motor
F G servo control
Aluminum die Cast
Diameter 30 4 cm (12 inches)
334/3 rpm and 45 rpm
6% adgustment range
Tracking error angle:
Offset angle:
Stylus pressure
adjustment range:
Applicable cartridge
weight range:
Headshell weight:
Phono cable
capacitance:
English {XMI is available in Central South America. 4
Specifications Specifications are subject to change without notice for further improvement
Weight and dimensions shown are approximate
I General Wow and flutter: o 045% WRMS (JIS 05521)
Power supply: 110-120/220-240 V. 50 or 60 Hz 350 06% Peak (IEC 98A Weighted)
Power consumption: 3 w Rumble: ,70 as (IE0 98A Weighted)
Dimensions: 43 X 10 6 >( 37 5 cm _
(W>
Maximum height when top Type: Universal tonearm
(dust cover) is open 8" shaped tubular arm
43 X 37 X 42 cm Static balanced type
(16-15/16"><14-9/16><1647/32") Ellective length: 230 mm (9»1/16")
Weight: 4 2 kg (93 lb) Overhang 15 mm (19/32)
Within 2°32 at the outer groove
of 30 cm (12") record
Within 0°32' at the inner groove
of 30 cm (12") record
22°
0-259
5-759
89
135 pF
Technics
Matsushita Electric Trading Co., Ltd.
P O Box 288, Central Osaka Japan
