Technics SJHD 501 Service Manual
This is the 65 pages manual for Technics SJHD 501 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Technics SJHD 501 Service Manual (Ocr-read)
Page 1
Specifications SystemMinidisc digital audio system RecordingMagnetic field modulation direct overwrite ReadingNon-contact optical system with Semiconductor laser (=780nm) Sampling frequency:44.1 kHz Cording system:ATRAC Channel:2channel, stereo Frequency response:10-20000Hz (±0.3dB) S/N Ratio (PLAY):90dB Wow and flutter:Below measurable limit Input Analog input (Level/impedance): 500mV/47kΩ ΩΩ Ω Digital input (Optical in 1, Optical in 2) Wavelength: 660nm Output Analog output (Level/impedance): 2.0V/600Ω ΩΩ Ω General Dimensions (WxHxD):196x104x237mm Weight:2.0kg Power supply:AC230-240V, 50Hz Power consumption:12W Notes: 1.Design and specifications are subject to change without notice. 2.Dimensions and weight are approximate. 3.Total harmonic distortion is measured by the digital spectrum analyzer. 1 2
Page 2
1. Accessories - AC power supply cord...............1pc. - Optical cable...............1pc. (RJL1X001B05D) 3
Page 10
11
Page 15
Fig.2 16
