Technics SC DV290 Owners Manual
This is the 52 pages manual for Technics SC DV290 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Technics SC DV290 Owners Manual (Ocr-read)
Page 1
2 RQT6894 Before use System Sound processor Stereo tuner/amplifier DVD/Video CD/CD changer Stereo cassette deck Supplied accessories Please check and identify the supplied acces- sories. Use numbers indicated in parentheses when asking for replacement parts. uAC mains lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For the United Kingdom For Australia and N.Z. (RJA0053-3X) (RJA0035-2X) For Continental Europe and Russia (RJA0019-2X) Note The included AC mains lead is for use with this unit only. Do not use it with other equipment. uRemote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For the United Kingdom, For Australia and N.Z. Continental Europe and Russia (EUR7702300) (EUR7702290) uRemote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 uFM indoor antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For the United Kingdom, For Australia and N.Z. Continental Europe and Russia (RSA0006-J) (RSA0007) uAM loop antenna set:(RSA0022-L). . . . . . . . . . . . . . . . . . . . . 1 uSpeaker leads (REE1234-1) . . . . . . . . . . 2 (REE1233-1) . . . . . . . . . . 2 (Red/Black) (Gray/Blue) uAntenna plug adaptor:(SJP9009). . . . . . . . . . . . . . . . . . . . . . 1 (Only for the United Kingdom) uVideo cord For the United Kingdom and Continental Europe (VJA0815-A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For Russia (RJL1P019B15) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For Australia and N.Z. (RJL1P019B15) . . . . . . . . . . . . . . . . . . . . 2 uRCAJ adaptor:(VFA0151-2). . . . . . . . . . . . . . . . . . . . . . . . . . . 1 (Only for the United Kingdom, Continental Europe and Russia) Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions care- fully. Front Center Surround Speakers SC-DV290 SH-DV290 SA-DV290 SL-DV290 RS-DV290 SB-DV290 SB-PC95 SB-PS95 www.panasonic.co.uk (for UK customers only) ³Order accessory and consumable items for your product with ease and confidence by telephoning our Customer Care Centre Mon–Friday 9:00am–5:30pm. (Excluding public holidays.) ³Or go on line through our Internet Accessory ordering application. ³Most major credit and debit cards accepted. ³All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd. ³It couldnt be simpler! Customer Care Centre For UK customers: 08705 357357 For Republic of Ireland customers: 01 289 8333 Technical Support For UK customers: 0870 1 505610 This Technical Support Hot Line number is for Panasonic PC software related products only. For Republic of Ireland, please use the Customer Care Centre number listed above for all enquiries. For all other product related enquiries, please use the Customer Care Centre numbers listed above. For United Kingdom and Republic of Ireland Unless otherwise indicated, illustrations in these operating in- structions are of the system for the United Kingdom, Continen- tal Europe and Russia.
