Technics SC DV170 Owners Manual
This is the 56 pages manual for Technics SC DV170 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Technics SC DV170 Owners Manual (Ocr-read)
Page 1
2 RQT5471 DVD/Video CD/CD changer (Back of product) System Sound processor Stereo tuner/amplifier DVD/Video CD/CD changer Stereo cassette deck Front Center Surround Subwoofer ¤ SC-DV170 SH-DV170 SA-DV170 SL-DV170 RS-DV170 SB-EH760 SB-PC75 SB-PS75 SB-W85 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instruc- tions carefully. These operating instructions are applicable to the following system. CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORM- ANCE OF PROCEDURES OTHER THAN THOSE SPECI- FIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. CAUTION! DO NOT INSTALL OR PLACE THIS UNIT IN A BOOK- CASE, BUILT IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. EN- SURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING. Supplied accessories Please check and identify the supplied accessories. ¸ AC mains lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc. For the United Kingdom For Australia and N.Z. (VJA0733) (RJA0035-X) For others (RJA0019-X) ¸ Power plug adaptor (SJP5213-2) . . . . . . . . . . . . . . 1 pc. (Except for the United Kingdom, Continental Europe, Russia, Australia and N.Z.) ¸ Remote control transmitter . . . . . . . . . . . . . . . . . . . 1 pc. For the United Kingdom, For others Continental Europe, Australia (RAK-EHA33WH) and N.Z. (RAK-EHA32WH) ¸ Remote control batteries . . . . . . . . . . . . . . . . . . . 2 pcs. ¸ FM indoor antenna . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc. For the United Kingdom, For others Continental Europe, and (RSA0006-J) Russia (RSA0007) ¸ FM antenna plug adaptor (SJP9009) . . . . . . . . . . . 1 pc. (Only for the United Kingdom) ¸ AM loop antenna set (RSA0022-J) . . . . . . . . . . . . . 1 set ¸ Speaker cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 pcs. (REE0393) (REE0984) (REE0985) (Red0 Black) (Blue 0Black) (Gray 0Black) ¸ Video cord (RJL1P019B15) For the United Kingdom and Continental Europe . . 1pc. For others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 pcs. ¸ RCAJ adaptor (VFA0151-1) . . . . . . . . . . . . . . . . . . . 1 pc. (Only for the United Kingdom and Continental Europe) Use numbers indicated in parentheses when asking for replacement parts. CAUTION! The AC voltage is different according to the area. Be sure to set the proper voltage in your area before use. (For details, please refer to page 5.) (Except for the United Kingdom, Continental Europe, Russia, Australia and N.Z.) ¤Except for the United Kingdom, Continental Europe, Australia and N.Z. Speaker CLASS 1 LASER PRODUCT DANGER LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM. ADVARSEL LASERSTRÅL NG VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSÆTTELSE FOR STRÅLING. VARO! AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN. VARNING LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN. ADVARSEL LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN. VORSICHT LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET. NICHT DEM STRAHL AUSSETZEN. DANGERS RADIATION LASER LORSQUE OUVERT. ÉVITER TOUTE EXPOSITION AU FAISCEAU. (Indersiden at apparatet) (Tuotteen sisällä) (Apparatens insida) (Produktets innside) (Im Inneren des Gerätes) (Inside of product) (Intérieur de Iappareil)
Page 2
3 Before use RQT5471 Safety precautions Placement Set the system up on an even surface away from direct sunlight, high temperatures, high humidity, and excessive vibration. These conditions can damage the cabinet and other components, thereby shortening the units service life. Place it at least 15 cm away from wall surfaces to avoid distortion and unwanted acoustical effects. Do not place heavy items on the unit. Voltage Do not use high voltage power sources. This can overload the unit and cause a fire. Do not use a DC power source. Check the source carefully when setting the unit up on a ship or other place where DC is used. AC mains lead protection Ensure the AC mains lead is connected correctly and not dam- aged. Poor connection and lead damage can cause fire or electric shock. Do not pull, bend, or place heavy items on the lead. Grasp the plug firmly when unplugging the lead. Pulling the AC mains lead can cause electric shock. Do not handle the plug with wet hands. This can cause electric shock. Foreign matter Do not let metal objects fall inside the unit. This can cause electric shock or malfunction. Do not let liquids get into the unit. This can cause electric shock or malfunction. If this occurs, immediately disconnect the unit from the power supply and contact your dealer. Do not spray insecticides onto or into the unit. They contain flam- mable gases which can ignite if sprayed into the unit. Service Do not attempt to repair this unit by yourself. If sound is interrupted,\ indicators fail to light, smoke appears, or any other problem that is no\ t covered in these instructions occurs, disconnect the AC mains lead and contact your dealer or an authorized service center. Electric shock or damage to the unit can occur if the unit is repaired, disas- sembled or reconstructed by unqualified persons. Extend operating life by disconnecting the unit from the power source if it is not to be used for a long time. Table of contents Before use Safety precautions . . . . . . . . . . . . . . . . . . . . . . . 3 Caution for AC Mains Lead . . . . . . . . . . . . . . . . . 4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Basic connections . . . . . . . . . . . . . . . . . . . . . . . . 6 Optional antenna connections . . . . . . . . . . . . . . 7 Television settings . . . . . . . . . . . . . . . . . . . . . . . 8 Front panel controls . . . . . . . . . . . . . . . . . . . . . . 9 The remote control . . . . . . . . . . . . . . . . . . . . . . . 11 Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Turning DEMO off . . . . . . . . . . . . . . . . . . . . . . . . 12 Saving power in the standby mode . . . . . . . . . . 12 Region numbers . . . . . . . . . . . . . . . . . . . . . . . . 13 Types of discs . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Basic operations Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14Normal play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . . 14 Skip/Search/Still picture(Pause)/Slow-motion play/ Frame-by-frame viewing function . . . . . . . . . . . . . . . . . . . . . . 16 Changing soundtrack, subtitle languages and angles . . . . . . . . 17 Using menus to play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Changing the picture quality for movie viewing . . . . . . . . . . . . . 18 Marking a position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Repeat function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . 19 Program play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . 20 Random play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ . . . 21 Starting play from a specific track . . . . . . . . . . . . . . . . . . . . . . . 21 Using GUI screens . . . . . . . . . . . . . . . . . . . . . . . 22 The radio: manual tuning . . . . . . . . . . . . . . . . . . 24 The radio: preset tuning . . . . . . . . . . . . . . . . . . 25 Cassette tapes . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Changing sound field and quality Changing sound field and quality . . . . . . . . . . . 28 Boosting the super woofer . . . . . . . . . . . . . . . . . 29 Enjoying surround sound . . . . . . . . . . . . . . . . . . 30 DOLBY DIGITAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \ 32 DOLBY PRO LOGIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 SUPER SURROUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 SIMULATED STEREO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Surround effects . . . . . . . . . . . . . . . . . . . . . . . . . 34 Recording operations Before recording (Deck 2 only) . . . . . . . . . . . . . 36 Recording discs . . . . . . . . . . . . . . . . . . . . . . . . . 38 Recording the radio . . . . . . . . . . . . . . . . . . . . . . 39 Tape-to-tape recording . . . . . . . . . . . . . . . . . . . . 39 Convenient functions Enjoying KARAOKE . . . . . . . . . . . . . . . . . . . . . . 40 Using the timers . . . . . . . . . . . . . . . . . . . . . . . . . 42 Initial settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Changing the sound range display . . . . . . . . . . 50 Muting the volume . . . . . . . . . . . . . . . . . . . . . . . . 50 Using headphones (not included) . . . . . . . . . . . 50 External unit connections . . . . . . . . . . . . . . . . . 51 Using other equipment . . . . . . . . . . . . . . . . . . . . 52 Reference Technical specifications . . . . . . . . . . . . . . . . . . . 53 Troubleshooting guide . . . . . . . . . . . . . . . . . . . . 54 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Disc symbols used in these operating instructions The functions you can use depend on the type of disc you play. These marks are used to indicate which type of disc is ex- plained. [DVD] : Feature can be used with DVD-Video [V-CD] : Feature can be used with Video CD [CD]: Feature can be used with Audio CD Some features cannot be used even if these symbols are indi- cated.
Page 44
45 Convenient functions RQT5471 1 2 3 EN ER RE URN 3D AI E / M EQ BAV EFFECT H ANGLE SLEEP MARKEROP MENU SUBT TLE 7890 j / / DISC PLAY MODECANCEL AUD O U PRO LOGIC CH SELECTTEST G TAL S WOOFER SUPER SRND Ú/gÛ È VOLUME µ VCR(EXT)/ VDP(A X) APE/ DECK 1/2 UNER/ BAND DVD SLOW SEARCH MUTING SKIP SHIF 123 456 MENU EQ SETUPDISPLAY MIX 2CH 2, 3 1 1 RETURN SHIFT ENTER 1 Disc Languages Level 82 Ratings 3 Menu Language 4 On-Screen Messages 5 TV Aspect 6 Speaker Setting Press RETURN to exit 9 Other Settings English 4:3 1 Disc Languages Level 82 Ratings 3 Menu Language 4 On-Screen Messages 5 TV Aspect 6 Speaker Setting Press RETURN to exit 9 Other Settings English 4:3 SETUP ENTER DVD a Numbered buttons Initial settings Changing the initial settings Remote control only Once the initial settings have been completed, the system can always be operated under the same settings. Preparation: Press [DVD] to select DVD as the source. 1 While stopped Press [SHIFT] r [SETUP]. The initial settings menu is displayed. 2 Press [3 ] or [4] to highlight an item, and press [ENTER]. 3 Press [ 2, 1 , 3 , 4 ] to select an item and press [ENTER]. Repeat step 3 as the menus require to make changes. Steps 2 and 3 can also be done with the numbered buttons. Press the number next to the required item. For example, press [3] to select 3 Menu Language. To return to the previous screenPress [RETURN]. To exit the initial settings menu Press [RETURN]. Note The initial settings menu will not be displayed if one of the program/ random/ALL DISC modes is activated. b (On the TV screen)
