Technics SATX 30 Service Manual

Page 1

ORDER NO. AD9702026A2

, Service Manual

Receiver

AV Control Stereo Receiver Dfi- SA TX 3 O

PRO-LOGIC

Colour (K) Black Type

Areas
E ............. Europe.
EB ............. Great Britain.
EG ............. Germany and italy.
. ' *Manufactured under license from Dolby Laboratories Licensing

Corporation. Additionally licensed under one or more of the follow
ing patents: us. numbers 3,632,886, 3,7,56,792 and 3,959,590;
Canada numbers 1,004,603 and 1,037,877..

"Dolby" and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.

[ Please file and use this manual together with the service manual for Model No. SA-TX50, Order No. AD960715508. ]

Notes: OThis simplified service manual is provided to indicate the main differences between the original model No. SA-TXSO (E)
and the subsequent model No. SA-TX30 (E, EB, EG).
I Refer to the Specifications, Schematic Diagram, Printed Circuit Board Diagram, Replacement Parts List, Cabinet Parts
Location and Packaging of this service manual.

A WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. it
does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

©1997 MatSUShita Electric industrial 00., Ltd.

. ® All rights resented. Unauthorized copying and
ec nlcs distribution is a violation of law.
