Technics®
AV control stereo receiver

~ SA-GX1 90

Operating Instructions

V Belore connecting.-0peratlng or adiusllng this product, please
read these, instructions completely.

ROT2696-B -

Page 2

Dear Customer

Thank you for purchasing this Technics product.
For optimum performance and safety, please read
these instructions carefully.

(For areas except Australia and NZ.)

CAUTION:

The AC voltage differs according to the area.
Be sure to set the proper voltage In your area
before use.

(For details, please refer to the page B.)

Please check and identify the supplied
accessories.

E] AC power supply cord (1)

(For Australia and N1.)

(For others)

[I AM loop antenna set
0AM loop antenna (1)
0 AM antenna holder (1)
0 Screw (1)

D FM indoor antenna (1) DPower plug adaptor (1)
(Not supplied for

Australia and N1.)

Q

D Remote control
transmitter (1 )

D Antenna plug (1)

D Batteries (2)
(UM-4, ",AAA R03)

4::1

Before use

Suggestions for safety . i .r 3
Technical specifications. . 4
Front panel controls .............................. 5

Connections

Equipment connections H
Antenna connections
Speaker connections rrrrrr

Listening

Basic operations rrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrrr 11
To adjust the tone quality .......
To adjust the sound balance
To mute the sound level ........

When listening through headphones . 12
Listening to radio broadcasts ............. .13
Direct access tuning ........... 13
Sequential tuning ............... .. 14
Preset tuning ......................................... 14
Recording
Making a recording ............................... 1B

Tape recording on the tape deck or digital compact
cassette (DOC) ....................

VCR (VCR 1) recording from an audio source .r ,. 17
Recording from VCR 2 to VCR 1 ........................ 17
Using the remote control
Remote control operation ....................... 13
Reference
Troubleshooting guide ............... Back cover

(For Australia and N1)

THIS TUNER/RECEIVER IS CAPABLE OF RECEIVING THE
NEW AM STEREO BROADCASTS FROM THE AM BAND
RADIO STATIONS HOWEVER LIKE MANY TUNERS AND
RECEIVERS CURRENTLY AVAILABLE ON THE MARKET IT
WILL REFRODUCE THIS AM STEREO SIGNAL ONLY IN AM
MONO, WHICH, IN EFFECT. IS OF NO LESSER QUALITY
THAN YOUR EXISTING AM MONO TUNER/RECEIVER.
