Service Manual

TOP NEXT

ORDER NO. MD0302054C2

CD Stereo System

| SA-AKZIOE
SA-AKZIOEB
SA-AKZIOEG
Colour
(S)... Silver Type
TAPE SECTION :

SG-ZW MECHANISM SERIES

Service

ellulr 5841910 SA-

Manual

(2'0

rafgn'ifas.
Specifications

AMPLIFIER SECTION
RMS Power output
um Touil harmonic distortion
lkHz. both channels driven
(Low channel) 55 w per channel (on )
IOkHz, both channels driven
(High channel) 55 w per channel (on)
Total BirAmp power 110 w per channel
Input sonsttivity
AUX 250 mV
Input Impedance
AUX 13.3 kn

FM TUNER SECTION
Frequency range 87.50 , [08.00 MHz (50 kHz steps)
Sensitivity Hip V (ll-1F)
S/ N 26 dB [.5 p v
Antenna terminal(s) 75g: (unbalanced)

AM TUNER SECTION
Frequency mg: 522 . 1529 kHz (9 kHz steps)
Sensitivity
S/ N 20 dB (at 999 kHz) soup w m

CASSETTE DECK SECTION
Track system 4 track. 2 channel
Heads
Record/ playback Solid permalloy head
Erasure Double gap ferrite head
Motor DC servo motor
Recording system AC bias 100 kHz
Erasing system Ac erase 100 kHz
rape speed 4.8 cm s
Overall frequency response (+ 3 dB, .5 dB at DECK our)
NORMAL (TYPE I) 35 Hz ,14 kHz
8/ N 50 dB (A weighted)

Wow and flutter

Fast forward and rewind time

CD SECTION
Sampling frequency
Dccol'ding
Pickup
Beam souree/ wavelength
Number of channels
Frequency response
Wow and flutter
Digital filter

Di' A converter

0. l 8% (w RM S)
Approx. 120 seconds with

C760 cassette tape

44.1 kHz
16 bit linear

Semiconductor laserl 780 nm
Stereo

20 Hzr 20 kHz(+ l. VZdB)
Below measurable limit

8 fs

MASH [I bit DAC)
