Technics RSAZ 6 Service Manual

Page 1

Stereo Cassette Deck

*-
o_

l

Please file and use this manual together with the service manual for
Model No. RS-AZ7, Order No. AD960101702.

i

Note: 0 This service manual is provided to indicate the main differences

between the original model No. RS-AZ7 (E) and the subsequent model
No. RS-A26 (E, EB, EG).

ISPECIFICATIONS

RS-AZ7 (E)

ORDER NO. AD9602020A2

Service Manual

Cassette Deck

, RS-AZ6

Colour

(K)...Black Type

Area
Suffix for
Model No. Area Colour
(E) Europe.
(EB) Great Britain. (K)
(EG) Germany and ltaiy.

* Dolby noise reduction and HX Pro headroom extension
manufactured under license from Dolby Laboratories
Licensing Corporation. HX Pro originated by Band and
Olufsen. "Dole', the double-D symbol and HX PRO"
are trademarks of Dolby Laboratories Licensing
Corporation.

CHANGES

IGeneral

Weight

Power consumption

26W
4.2kg

up

RS-A26 (E, EB, EG)

IGeneral
Power consumption 25W
Weight 3.9kg

.CHANGE IN REPLACEMENT PARTS LIST (RS-A27 Service Manual of pages 56~60.)

Notes: 0 Mentioned in this parts list is only those different from Model No. RS-AZ7 (E). All other parts are the same as for

Rs-Az7 (E).

I important safety notice:

Components identified by A mark have special characteristics important for safety.
W Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise
(resistors), etc, are used.
When replacing any of components, be sure to use only manufactures specified parts shown in the parts list.
0 The parenthesized indications in the Remarks columns specify the areas. (Refer to the cover page for area.) Parts
without these indications can be used for all areas.
Change of Part No.
R f. N . Part N me & Des ri tion R arks
e 0 RS-AZ7 (E) fl) RS-A26 (E. EB, EG) a c p 6'
INTEGRATED CIRCUIT(S)
lC4 | AN65588FE2 l - l BUFFER AMP Deletion
TRANSISTOR(S)
Q101-104 28K36QGRTPE2 - TRANSISTOR Deletion
0105, 106 ZSB7OSQRSTX - TRANSISTOR Deletion
Q107. 108 28D601QRSTX - TRANSISTOR Deletion
Q109 DTC144EKT147 - TRANSISTOR Deletion
v
. ® © 1996 Matsushita Electric |ndustrial'Co., Ltd.
All rights reserved. Unauthorized copying and
GO nlcs distribution is a violation of law.
