Technics RS 678 US Brochure

Page 1

Microphone RP-3200ESingle Point Stor.o Microphone High sensitivity thanks lo perpendi- cular arrangement of the two built-in elements and six Field Effect Transistols incorporated in the built-in amplifier. Advanced matrix circuitry eliminates cross talk and attains superb stereo ssparalron. RP-3550ECompact, Moderately Priced Unl-dirgctionrl Elacttot Condenser Microphone with Fixed Wind3c?oonRecommended to ownels of high- grad6 tape decks. The built-in amplitier incorporates high-quality FET's for crystal clear, noise-free sound. Wind blast elfectively counter-acted by a double-mesh windscreen. RP-3830EStylish High Ouality Uni-diroction- al Stick Miko wlth Trendy Re- movrble Wind3creon The head amp includes high-impe- dance low-noise FET's. Tonal quality can be regulaled with the low cut switch. The cable connector is suirable for both switchcratt and cannon plugs. RP-3850ESlimline Uni-dir.ctional Macro- phonc with Sturdy Bomovablo WlndacroonA low cut filte; allows adiustment ot lonal quality and reduction of boomi - ness. PAD switch lowers sensitivity by 10 dB. And since the max. SPL as 128 dB, even the dealening roar of a low flying jet aircraft can be picked up with distortion-free claiitv. BP-3200E RP-3550E RP-3830E RP-3850E Specifications Track System: Tape Speed: Wow and Flutter: Frequency Response: 4-track 2-channel stereo recording ahd playback 4.8 cm/s, (1* ips) 0.06% (wRMs), +0.15% (DrN) CrO2 tape; 20 - 18.000 Hz 25-15,000 Hz (DlN) 30-'14,000 Hz+3dB Normal tape; 20-16,000 Hz 25-14,000 Hz (DlN) 30 - 13,000 Hz * 3dB Signal-to-Noise Ratio: Dolby NR in; 62 dB (above 5kHz) Dolby NR out; 52 dB (signal level : 250nWb/m) Fasl Forward and Rewind Time: Approx. 90 seconds with C-60 cassette tape lnputs: MIC; sensitivity 0.3mV applicable microphone imoedance 600 O -20k O LINE; sensitivity 60mV, input impedance 68k O DIN; sensitivity 16mV, input imDedance 2.2k o Outputs: LINE; output level 42OmV, load impedance 50k O over DIN; output level 420mV, output imoedance 2.5k Q HEADPHONE; output level 65mV, load impedance 8 Q Motors: Heads: Power Requirements: Power Consumption: Dimensions(WxHxD): Weight: 2-motor system 1-F.G. Servo DC motor for caostan drive1-DC motor for reel table drive 2-head system 1-HPF head for rec/playback 1-Double-gap Ferrite head for eras ure AC 220 V 50/60 Hz AC 240 V 50/60 Hz for England onlY 20w45.0cmx17.3cmx34.1cm(171"x6+"x13i")10 ks (22 lbs) @Technics Matsushita Electric Specifications are subject to change without notice. AR D-520602S-EFG Printed in Japan
