Teac CT M48 Service Manual
This is the 40 pages manual for Teac CT M48 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Teac CT M48 Service Manual (Ocr-read)
Page 2
CONTENTS
Contents and Specifications ..................................................................................... 2
Safety Precautions ................................................................................................... 3 .
Servicing Precautions ............................................................................................... 4
Controls Location ..................................................................................................... 6
Antenna Connections ............................................................................................... 7
Disassembly Instructions .......................................................................................... 8
Parts Location of Main Chassis ................................................................................ 9
Adjustment Instructions ............
Circuit Description
Troubleshooting Guide
Block Diagram
Wiring Diagram .
Component Location Guide
Printed Circuit Board
Expolded View
Terminal View of Semiconductor .
Replacement Parts List ..
Schematic Diagram .....
SPECIFICATIONS .
Power Source .. AC 180 V-270 V, 50 Hz
Power Consumption . ........................... 70 W
Receiving TV System ............... CCIR Standard
Colour Receiving System ................................................ PAL-BIG
Receiving Channels ....... VHF Low: 2-4 CH., VHF High: 5-12 CH, UHF: 21-69 CH
CATV: 31-825
Intermediate Frequency
Picture .................................................................................................... 38.9 MHz
Sound .................................................................................................... 33.4 MHz
Colour .................................................................................................. 34.47 MHz
Tuning ................................................................................ 39 Voltage Synthesizer
Audio Output ......................................................................................................... 2 W
Antenna Input Impedance ................................................................. 75 ohm IEC Type
(300 ohm using balun supplied)
Picture Tube ~ ................................................................................................ 370RE322
Speaker ................................................................................................... 90 x 50 mm
Dimension .................................................................. 360(W) x 364(H) x 387(D) mm .
Weight ............................................................................................................. 11.7 Kg
