Teac CT 341 Mk2 Service Manual

Page 19

MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P

PART NUMBER DESCRIPTION QTY.

1057180103708 FIXED INDUCTIVE COIL 18 UH 1
L302

1057201106702 CHOKE COIL 200UH 10% CH90127 201K (ELEC PRODUCT) 1
L903

1057270103708 FIXED INDUCTIVE COIL 27UH 1
L601

1057689103708 FIXED INDUCTOR COIL 6.8 UH +710% AXIAL 1
L301

1057828103708 FIXED INDUCTIVE COIL 0.82 UH +710% AXIAL 1
L101

1077105500766 SOUND TRAP CERAMIC FILTER 5.5MHZ WEI HAW 1
CF102

107*30550016 SOUND BYPASS CERAMIC FILTER 5.5MHZ WEI HAW 1
CF101

1077808000766 RESONATOR 8MHZ 1
X601

1137101105717 CARBON FILM RESISTOR 100 OHM 1/4W +75% 4
R314,316,318,438

1137101205712 CARBON FILM RESISTOR 100 OHM 1/2W +75% 1
R649

1137102105717 CARBON FILM RESISTOR 1K OHM 1/4W +75% 0
R140,134,114,432,669,326,004,006,009,329

1137102305775 METAL OXIDE FILM RESISTOR 1K OHM 1W +75% 1
R411

1137103105717 CARBON FILM RESISTOR 10K OHM 1/4W +75% 9
R418,908,204,650,309,129,130,122,622

1137103105717 CARBON FILM RESISTOR 10K OHM 1/4W +75% 0
R104,120,118,640,617,005,013,010,012,108

1137103105717 CARBON FILM RESISTOR 10K OHM 1/4W +75% 3
R109,110,623

1137104105717 CARBON FILM RESISTOR 100K OHM 1/4W +75% 7
R422,642,634,119,681,682,CF103

1137104205712 CARBON FILM RESISTOR 100K OHM 1/2W +75% 1
R923

1137104305775 METAL OXIDE FILM RESISTOR 100K OHM 1W +75% 1
R921

1137109205712 CARBON FILM RESISTOR 1 OHM 1/2W +75% 1
R410

1137120305775 METAL OXIDE FILM RESISTOR 12 OHM 1W +75% 1
R911

1137120405775 METAL OXIDE FILM RESISTOR 12 OHM 2W +75% 1
R920

1137120505775 METAL OXIDE FILM RESISTOR 12 OHM 3W +75% 1
R414

1137121105717 CARBON FILM RESISTOR 120 OHM 1/4W +75% 1
R648

1137122105717 CARBON FILM RESISTOR 1.2K OHM 1/4W +75% 3
R407,665,303

1137123105717 CARBON FILM RESISTOR 12K OHM 1/4W +75% 4
R436,441,327,306

1137124105717 CARBON FILM RESISTOR 120K OHM 1/4W +75% 1

R451

6/17
