Teac A BX10 MK II Owners Manual
This is the 20 pages manual for Teac A BX10 MK II Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Teac A BX10 MK II Owners Manual (Ocr-read)
Page 1
– 2 – IMPORTANT SAFETY INSTRUCTIONS CAUTION: ORead all of these Instructions. O Save these Instructions for later use. O Follow all Warnings and Instructions marked on the audio equipment. 1) Read Instructions - All the safety and operating instructions should be read before the product is operated. 2) Retain Instructions - The safety and operating instructions should be retained for future reference. 3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to. 4) Follow Instructions - All operating and use instructions should be followed. 5) Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 6) Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards. 7) Water and Moisture - Do not use this product near water _ for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like. 8) Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart,\ stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturers instructions, and should use a mounting accessory recommended by the manufacturer. 9) Aproduct and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 10) Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to prot\ ect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilati\ on is provided or the manufacturers instructions have been adhered to. 11 ) Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure\ of the type of power supply to your home, consult your product dealer or\ local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 12) Grounding or Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the\ outlet, try reversing the plug. If the plug should still fail to fit, contact yo\ ur electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. 13) Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon\ or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.\ 14) Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system\ is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. "Note to CATV system installer: This reminder is provided to call the CATV system installers attention to Section 820-40 of the NEC which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point\ of cable entry as practical. ANTENNA LEAD IN WIRE ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H) NEC - NATIONAL ELECTRICAL CODE ELECTRIC SERVICE EQUIPMENT Example of Antenna Grounding as per National Electrical Code, ANSI/NFPA 70 GROUND CLAMP 15) Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time\ , unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges. 16) Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. 17) Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in risk of fire or electric shock. 18) Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never \ spill liquid of any kind on the product. 19) Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 20) Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) when the power-supply cord or plug is damaged. b) if liquid has been spilled, or objects have fallen into the product. c) if the product has been exposed to rain or water. d) if the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician t\ o restore the product to its normal operation. e) if the product has been dropped or damaged in any way. f ) when the product exhibits a distinct change in performance _ this indicates a need for service. 21) Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards. 22) Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. 23) Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the manufacturer. 24) Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including\ amplifiers) that produce heat.
Page 2
– 3 – Before Use Read This Before Operating IMPORTANT (for U.K. Customers) DO NOT cut off the mains plug from this equipment.If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer. If nonetheless the mains plug is cut off, remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply. If this product is not provided with a mains plug, or one has to be fitted, then follow the instructions given below: IMPORTANT. The wires in this mains lead are coloured in accordance with the following code: GREEN-AND-YELLOW: EARTH BLUE: NEUTRAL BROWN: LIVE W ARNING: This apparatus must be earthed. As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows. The wire which is coloured GREEN- and-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol ©or coloured GREEN or GREEN-and-YELLOW. The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED. When replacing the fuse only a correctly rated approved type shouldbe used and be sure to re-fit the fusecover . IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN. ●Place the amplifier on a hard flat surface. ● The ventilation holes should not be covered. Make sure there is at least 20 cm (8 inches) of space above and at least 5 cm (2 inches) of space besides the amplifier. Do not place CD player or other equipment on top of the amplifier. ● Avoid placing it in direct sunlight or close to a source of heat. Also avoid locations subject to vibrations and excessive dust, heat, cold or moisture. ● Do not open the cabinet, as this might result in circuitry damage or electrical shock. ● When removing the power plug from the wall outlet, always pull directly on the plug; never yank the cord. ● Do not attempt to clean the unit with chemical solvents, as this might damage the finish. Use a clean, dry cloth. ● Keep this manual in a safe place for future reference. Notes on Power Sources ●Plug the AC power cord into an AC wall receptacle. The correct voltage for operating your unit is printed on the rear panel. ∑ Main POWER Switch ●The main POWER switch is located on the rear of the unit. Press the ON side of this rocker (seesaw) switch to turn power ON (standby position); press the OFF side to turn power off. Whenever the power is ON, the indicator on the front panel glows red. Note: Leave this main power switch ON at all times. ∑ AC IN Socket Plug the provided AC power cord into this socket. ∑ Fuse Holder After replacing fuses, be sure to close the fuse compartment until it clicks. When operating the remote control unit, point it towards the remote sensor on the front panel of the unit. ∑ Battery Installation Remote Control Unit 1. Remove the battery compartment cover. 2. Insert two AAA (R03, UM-4) dry batteries. Make sure that the batteries are inserted with their positive ±and negative -poles positioned correctly. 3. Close the cover until it clicks. Battery Replacement. If you notice that the distance between the remote control unit and the player for correct operation becomes shorter, it indicates that the batteries are exhaust- ed. In this case replace the batteries with new ones. Precautions concerning batteries … Be sure to insert the batteries with correct positive ±and negative - polarities. … Use batteries of the same type. Never use different types of batteries together. … Rechargeable and non-rechargeable batteries can be used. Refer to the precautions on their labels. … When the remote control unit is not to be used for a long time (more than a month), remove the batteries from the remote control unit to prevent them from leaking. If they leak, wipe away the liquid inside the battery compartment and replace the batteries with new ones. … Do not heat or disassemble batteries and never dispose of old batteries by throwing them in fire. Main fuse Spare fuse
Page 13
Caratteristiche e comandi – 14 – 0ey q 0 w rt Pannello posteriore 0 Terminali dei diffusori Collegare il diffusore sinistro a "SPEAKER L" e quello destro a "SPEAKER R". Controllare che i diffusori siano collegati in fase. Attenzione: I corto circuiti dei terminali dei diffusori, dei cavi di terra o dei cavi del segnale possono danneggiare l'amplificatore. I corto circuiti fra i terminali dei diffusori fanno saltare un fusibile. Prima di collegare o scollegare i cavi dei diffusori o quelli del segnale, spegnere sempre il sistema. Attenzione: L'uscita dei diffusori è bilanciata. Non collegarvi alcun componente la cui uscita sia non bilanciata (ad esempio analizzatori di spettro o altoparlanti elettrostatici). q Connettore d'ingresso bilanciatoL'ingresso bilanciato viene collegato con spinotti XLR in accordo con le prescrizioni IEC. PIEDINO 1: TERRA PIEDINO 2: + PIEDINO 3: – wTerminale per messa a terra (GND) Collegare a questo terminale il cavo per la messa a terra del giradischi. e Prese del segnale audio ● Prese di ingresso AUXCollegare le prese di uscita audio del VCR a queste prese. ● Prise di ingresso CD Collegare a queste prese le prese (LINE OUT) di uscita del lettore CD. ● Prese di ingresso TUNERCollegare le prese di uscita del sintonizzatore a queste presse. ● Prese TAPE 1 PLAY/REC Collegare le prese di uscita (LINE OUT) del deck alle prese PLAY e collegare le prese di ingresso (LINE IN) del deck alle prese REC. ● Prese TAPE 2 MONITOR PLAY/RECQueste prese vengono utilizzate per il collegamento di un secondo deck a nastro. Collegare le prese di uscita (LINE OUT) del deck alle prese PLAY, e collegare le prese di ingresso (LINE IN) del deck alle prese REC. r Presa AC IN (vedere a pag 12.) t Interruttore di corrente principale (POWER) (vedere a pag 12.) Premete il lato ON dell'interruttore per accendere l'unità (posizione di attesa). Nota: Lasciace questo interruttore di corrente principale su la posizione attivata (ON). y Portafusibili (vedere a pag 12.) Duplicazione di cassette Potete duplicare una cassetta dal registratore collegato alle prese TAPE 1 a quello collegato alle prese TAPE 2. La duplicazione in direzione opposta non è possibile. 1. Portare il registratore di riproduzione (TAPE 1) sul modo di riproduzione e quello di registrazione (TAPE 2 MONITOR) sul modo di registrazione. Regolare quindi il livello di registrazione su di un valore ottimale consultando in proposito i manuali delle due unità. 2. Portare il selettore d'ingresso sulla posizione tape 1 e portare il comando tape 2 monitor su source. Dati Tecnici Potenza di uscita continua (RMS): 100W + 100W (20 - 20.000 Hz, 8 ohm) 160W + 160W (20 - 20.000 Hz, 4 ohm) Potenza di uscita dinamica (EIA): 120W + 120W (8 ohm) 220W + 220W (4 ohm) Distorsione armonica: (alla potenza di uscita continua) 0,04% (20 - 20.000 Hz, – 6 dB, 8 ohm) 0,06% (20 - 20.000 Hz, – 6 dB, 4 ohm) Sensibilità/impedanza d'ingresso: CD, TUNER, AUX, TAPE; 300 mV/20 k ohm BALANCED (XLR); 600mV/10 k ohm Livello/impedenza di uscita: TAPE 1, TAPE 2; 300 mV/100 ohm Rapporto S/N (IHF-A): CD, TUNER, AUX, TAPE; 104 dBA Risposta in frequenza: CD, TUNER, AUX, TAPE, BALANCED; 20 - 20.000 Hz, + 0 /– 0,8 dB Alimentazione/consumo: 120 V CA, 60 Hz, 5 A (modello per Canada et U.S.A./modello "exportazione generale") 220 V CA, 50/60 Hz, 500 W (modello per Corea) 230 V CA, 50 Hz, 500 W (modello per l'Europa et Gran Bretagna/modello "exportazione generale") Dimensioni (L x H x P): 442 x 103 x 383 mm Peso (netto): 12,0 kg Accessori: Telecomando (RC-685) x 1, Cavo di alimentazione x 1 Eventuali miglioramenti possono risultare in modifiche senza preavviso alle caratteristiche o ai dati tecnici. Pannello posteriore *Spegnere tutti i componenti prima di procedere ai collegamenti .
