INSTRUCTION MANUAL

I I I E A : STEREO TAPE DECK
® STEREO TAPE RECORDER

Page 2

. ,.. Arm-w

Your new equipment has been manufactured under the strictest quality control
procedures, each unit has been thoroughly checked at the factory. Should any damage
have any doubts as to its performance, contact your dealer as soon as possible.

Our investigation has shown that approximately 40% of the calls for service
immediately after purchase, result from improper operation of the equipment.
Therefore it is» important that you thoroughly read and understand this manual
before placing the unit in operation. A lack of, or improper cleaning can also result in
a degradation of performance. Careful observation of the cleaning and servicing hints
contained in this manual will contribute to a lengthened trouble free unit life. Please
consult the trouble shooting chart on page 14 before seeking service as most common
problems are thoroughly covered by this chart.

Service

Should the equipment need repair, contact the dealer where it was purchased, or

the authorized TEAC Service Center nearest you.

l)The Warranty period is described in the enclosed warranty card, read the card for
complete details.

2) For repairs after expiration of the warranty period a service charge will be made in
addition to the price of repair parts.

3) If only repair parts are required, place your order with your dealer, nearest TEAC
authorized Service Center.

Note

Although the unit may still dc under the Warranty period, you may be charged for
repairs made necessary by misuse, or damage incurred as a result of improper
operation. '

Page 8

Threading the Tape

Splicing the Tape

Be sure the control lever is in the STOP position.

A

l.llace an empty reel on the 9 right reel tahle and a full
reel on the 9 left reel table.

2, Use reel clamps to retain reels on the DIiCK.

3. Holding the end of the tape straight and flat between the
left and right hand, place in evenly in the slot of the head
housing.

4.Secure the end of the tape to the empty reel huh. (Do
not secure it with a reel clamp.)

S. Rotate the empty reel counterclockwise to remove any
slaek in the tape.

Should your tape be broken or should you desire to edit
a tape. use the procedures outlined below

Scissors: Completely demagnetize the scrssnrs by use of the
Head or Bulk demagnetiter~ Use of a magnetized scissors
will result in a Click at the spliced area.

Splicing tape: Use only a commercial splicing tape, Never
use Celophane (Scotch) tape as the adhesive will spread and
contaminate your recording heads.

Methm of splicing: Overlap the ends to be spliced by
approximately '5. inch. align them carefully then out
through the center of the overlapped area at a 60" angle,
The ends of the slanted cut tape are then huttcd together
and the splicing tape applied to the base side at the tape. To
insure l'irm adherence. the splice is placed on a hard surface
and the splicing tape rubbed briskly with your fingernails or
any hard smooth object. Next trim off any excess splicing
tape, cut slightly into the tape on both edges at the spliced
area. (See illustration).

Page 11

General Information and Precautions at Recording

The tape

The length of a recording tape as well as tlte recording
time. is determined by the reel diameter and the thickness
of the base material.

The use of a | 0| l/: mil base tape is recommended for 4
track hiin fidelity recording. Polyester base tape is preferred
for use in humid or extremely dry areas.

Three recording speeds are commonly used. 3%, and 7%
inches per second

7% ips is commonly used for home high fidelity
recording. Generally speaking, the higher the recording

speed. the better the fidelity. However. due to the extieme-
ly high quality of the TEAC tape decks. recordings of
excellent quality can be made at the lower speeds. This
provides maximum tape economy and extended playing
time.

The recording time indicated in the chart below is for one
single pass of the tape, therefore the total recording time
will either two or four times that indicated. depending upon
the method of recording.

Type Base Tape 7" elk d _ Typical 4 track tape brands on market
, ~ - . ecor in time me , , ;
(Code) material thickness '1 ape length 71/: Vim: Scotch l BASF Agfa SONY
, l , 7 __ ___ l .A 77 _
Standard Acetate l 52 ii 1% mil _370m _1200 ft 30 min. 60 min; a 111 l 51x52 78-100
_ Standard Polyester 52 pmlirriil '4 7 '
bong play Acetate 35 u l mil 550m [800 ft 45 min. 90 min; 3: I90 7 7
Long play _flycster r992. 1mil__ " " > 37 ~ .3. 150 F 111135 lE-SIK S-ISO
Long play POIYESBI l 35," lmil " ~ : " == 203 l LP-35Lll l PE-IioK . SLll-SSO
, , g , 7 l
Double play Polyester 1 28 ,1 V2 mil 740m 2400 it [60 min.l120min.l l DP-26LH t PE.46K 3-200

Good quality tape wound on correct reel

U:

Tape condition can be judged by the appearance

when wound on the reel and viewed from the side.

1) is it neatly wound? 2) ls there steps or irregularities in
the winding? 3) Is the color of base uniform as seen from
the side? 4) is the tape edge smooth?

V

k/

Spots seen on the edge indicate drop out (skipping of
sound)

b-

Creases extending from the center positively indicate uneven
stretching. This is caused by differences in temperature and
humidity.

V

k/

Fungus indicates old tape stored for a length of time under
high humidity. Sections where the splicing tape has been
applied are especially prone to support fungus growth.

Selecting the tape and reel

For recording, new tape is not necessarily needed as long
as it is of good quality as the erase head will erase the
previous recording as the new recording is made. However,
avoid using tapes whose coating is worn. peeled off or
stretched. is

i

If the color of the winding is different throughout the
reel it is an indication that two different types of tape have
been spliced in. In some cases, the color may differ
according to production lot even for the same type tape, or
between opposite sides of the wound tape.

Judging tape condition by how it travels.

Head

Tapes which snake up and down between the guides and
over the heads will inevitably lead to level fluctuations and
azimuth misalignment.

Head Finch roller CnDstan
/ /

Unevenly stretched tape which travels either higher or
lower than the true path of the tape will in extreme cases
drift off the pinch roller.

Head Pinch roller
/ \ \
w \
\
|
\
capstan

Snaky motion of unevenly stretched tape indicated by
arrows.
