Page 1
112mkII Technical Documentation 7733 Telegraph R oad - Montebello , CA 90640 - (323) 726-0303 - http://www .tascam.comAll features and specifications are subject to change without notice. C\ ontact y our local TASCAM representativ e for the latest information. Page 2 of 3112mkII_TECHDOC.pdf 041900 ARCHITECT'S SPECIFICATIONS The cassette pla yer/recorder shall utiliz e a two head cassette mechanism. Inputs connectors on the rear panel. The option of balancedXLR connectors shall be pro vided by the optional LA -112balancing kit. An additional pair of 1/4" inputs shall be located on the front panel. Lev els shall be displayed onlarge VU meters with peak LEDs for accur ate display of levels. The input lev el shall be controlled b y separate left and right controls on the front panel. Stereo output level shall also be pro vided on the front panel for convenience. Headphone output with lev el control shall be provided on the front panel. Monitor panel for selection between input monitor mode and automatic monitor mode. Dolb y™ B and C noise reduction shall be implemented and switched from the front panel. An MPX filter shall be switchable from the front panel. A pitchof pitch control, with a dedicated on/off control. The the R TZ function (R eturn to Zero) and two locate points. An additional separ ate button shall trigger the repeat function which will loop between locate 1 and locate 2. A location. A parallelremote control and tallies, and it shall be compatible withthe TASCAM RC -134 remote control. The form, taking three r ack spaces. The cassette mechanismshall have dimensions of 19" x 5 1/4" x 14" (W x H x D). Metric measurements : 482 x 132 x 356mm (W x H x D). The NOTE:Sound Contractor CD-ROM. Contact TASCAM for details. OPTIONAL REMOTE (RC-134) PARALLEL I/O Pin12345678910111213141516171819202122232425 SignalPLA Y InFFWD InREW InPA USE InST OP InREC In NO T USED NOT USEDTAPE DIRECTION T ally NOT USEDPLAY TallyFF T allyREW T allyPA USE T allySTOP T allyREC T ally NOT USED NOT USEDREEL PULSE NOT USEDRTZ InFADER ST ART In NO T USEDGROUND+5V (Max 50mA) Control I/O Legend 16 18 20 15 17 19 21 24 22 14 23 25 1 3 5 7 2 4 6 89 11 13 10 12 Parallel Control Notes: All command the chart at left. The commands are activ e when brought to ground for more than 50 milliseconds or longer. FADER ST ART function. Pla yback begins when the pin is brought to ground for more than 50 msec, and stops when the ground is released for more than 50 msec. Tally outputs tr ansport function when the pin is broughtto ground.
Page 2
112mkII Technical Documentation 7733 Telegraph R oad - Montebello , CA 90640 - (323) 726-0303 - http://www .tascam.comAll features and specifications are subject to change without notice. C\ ontact y our local TASCAM representativ e for the latest information. Page 3 of 3112mkII_TECHDOC.pdf 041900 FRONT AND BACK PANEL 112mkII rear panel shown with optional LA-112 balancing kit.
