Tandberg TPT 3001 Service Manual 3
This is the 8 pages manual for Tandberg TPT 3001 Service Manual 3.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Tandberg TPT 3001 Service Manual 3 (Ocr-read)
Page 2
Cabinet assembly
11
SPECIFY HIS WHEN ORDERING
Index Ordering No. Bukrivalsumlrknndnr)
Description (mm)
Reference
* Kabinet t -enhet
1 379324 Skinne
2 996913 Plate
3 346854 Skrue
4 379676 Skinne
5 996914 Plate
6 996924 Skinne
7 400602 Hyl se
8 401105 Skrue
9 996923 Skinne
10 375258 Plate
11 408921 Plate
12 405875 Vinkel
13 409661 Skrue
14 400480 Avstandsstykke
15 402786 Skrue
16 408928 Brakett
17 403533 Brakett
18 405214 Handtak
19 404819 Skrue
Cabinet assembly
Plate, front
Plate, top-front
Screw, 3.5 x 6.3 hex hd, with collar
Panel, back
Plate, top
Plate, side, left
Spacer, black plastic
Screw, M4 x 16 csk hd, black
Plate, side, right
Plate, bottom
Extra side panels.
Panel, side
Bracket, side panel
Screw, 3/8" No.4 csk hd, black
Spacer, black plastic
Screw, M4 x 25 csk hd, black
Extra 19 rack mount.
Bracket, rack mount, left
Bracket , rack mount , right
Handle
Screw, M4 x 12 csk hd, black
