Tandberg 72 72 B 74 74 B Service Manual

Page 2

Preface

This service manual covers the Tandberg tape re-
corder models 74 - 72 and 74B - 72 B.
The model 74 is a complete quarter-track, three
speed stereo, record. and playback unit with two
heads. It is equipped with separate record and play-
back preamplifiers for each channel. The combined
record/power output amplifiers can be switched be-
tween record amplifiers or playback power amplifiers.
The model 743 is similar to the model 74, but is fur-
nished with a playback pre-amplifier output stage, for
each channel, in addition to the combined record/
power output amplifier, and a center channel output.
The model 72 is the half-track version of the model 74.
The model 728 is the half-track version of the model
74 B.
All four models have exactly the same mechanical
system.
We hope that everyone concerned with our products
will find this service manual useful.

May 1964.

This second edition of the service manual has been
changed to incorporate certain modifications which
have been made in the tape recorder to improve the
equipment.

October 1965.
