Tandberg 3300 X Owners Manual

Page 2

Preparation tor use
Connections ......
Microphone
Stereo amplifier
Headphones
Copying of tape
Recording .....
Mono
Stereo ............. . ............ . ...........
Program monitoring during recording
Playback
Mono
Stereo
The recorder used as a microphone
amplifier
Mono
Stereo
Combined playback/amplifier function 9
Sound-0mm ........ .......... 10
A-test .............. 10
B~test
Mixing
Mono ..
Stereo .....
Language learning . ..
Echo ...................................... 12
Flying start - playback to recording 13
Program editing ...... ........ ...... 13
Four track recording and playback .
Degaussing 01 heads and tape path

uuuooaoumumhaaum

Tape splicing .. ............ . 15
Automatic stop . 15
Maintenance 16

Inspection 16

Cleaning ..... 16
Connection plugs 17
Microphone TMB 17
Function table ............. 18

Technical specifications ...................... 19

Tandberg Series 3300 X

Series 3300 X is a new and outstanding tape deck suited tor the world's most
discriminating markets in respect of quality and sound reproduction fidelity.
The recorder is equipped with the revolutionary Tandberg crosslield which
has extended the frequency range upwards and made the lover tape speeds
more uselul. The input dynamic range has been extended up to 66 dB. and
simultaneously the input signal/noise level has been improved.

Series aaoox has separate heads for recording and playback, rendering
choice of A- or B-test monitoring and enabling sound-on sound and echo
recording. The high sensitivity microphone inputs are intended tor dynamic
microphones with 200-700 ohm impedance. Separate inputs and outputs.
located on the bottom cover. are provided lor connection oi receiver and
amplifier. A last rise. slow-decay (peak reading) record level meter on each
channel indicates the program level applied to the record head. Stereo
headphones for monitoring can be connected to socket on the top plate.

The recorder features flying start from record to playback mode or vice
versa. Series 3300X can be used in playback mode and as a microphone
amplilier at the same time. This makes the recorder well suited as a central
unit in a music and speech distributing system.
