ecord gain control for adjust-

Record button. The tape recorder rs

set in record mode when the button is

dopiossed. The interlock button must
be depressed in order to operate

The interlock button
must be kept down

the record push-button.

when the record
push-button is
depressed.

Cartridge release button.

The tape stops automati-

cally and the cartridge is

released when the button
is depressed.

ment ol the recording level.
The control should. during re-
cording. be adjusted until the
pornter of the recording indi-
cator reads up to the red area.

Playfiacli Sutton. -
The tape recorder
is connected trom
record to playback

when the button

IS depressed.

Signal light.
Lights up
when the tape
recorder is set
for recording.

Start/stop button,
The tape stops
instantaneously

when the button is

depressed.

Signal light
Lights up
when the cur-
rent is
swrtched on.

Microphone contact.
DIN connector tor connec-
tion at dynamic micro-
phone with impedance

200 ohms.

~ -.1I«""""' Bit-8' .
uni-.1!

i.
. _.. ,.. . . . ,_. . ,"-..,

s_' new

H Al." STOP

TANDBERG 2

4 SERIES l3
2 ram

RKORD

Track selector
switch tor selec~
tron between track 1
(upper track) and
track 2 (lower
track]

Swrtch tor the automatic stop
mechanism which stops the tape
at the point or points where
electrically conductive tape has
been inserted.

Power switch.

Switches mains

current on and
ott.

3 posmon speaker selector
switch, INT position: Internal
speaker. EXT position:
Auxiliary speaker. INT+EXT
position: All speakers.

Volume control
knob controlling
the playback
volume.
