Sony zs xn 30 service manual
This is the 56 pages manual for sony zs xn 30 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony zs xn 30 service manual (Ocr-read)
Page 1
2 ZS-XN30 TABLE OF CONTENTS 1. SERVICING NOTES .............................................. 4 2. GENERAL .................................................................. 5 3. DISASSEMBLY 3-1. Disassembly Flow........................................................... 7 3-2. Cabinet (Lower).............................................................. 8 3-3. Main Chassis Section...................................................... 8 3-4. AUDIO Board, BATTERY Board.................................. 9 3-5. TUNER Board, CONTROL Board................................. 9 3-6. CD Block Section............................................................ 10 3-7. CD Lid............................................................................. 10 3-8. Cabinet Front (L)/(R) Assy............................................. 11 3-9. Cabinet Front (L) Sub Assy............................................ 11 3-10. Cabinet Front (R) Sub Assy............................................ 12 4. ELECTRICAL ADJUSTMENTS Tuner Section................................................................. 13 CD Section..................................................................... 15 5. DIAGRAMS 5-1. Block Diagram – CD SERVO Section –...................... 16 5-2. Block Diagram – TUNER Section –............................ 17 5-3. Block Diagram – MAIN Section –............................... 18 5-4. Note for Printed Wiring Boards and Schematic Diagrams....................................................... 19 5-5. Printed Wiring Board – CD Board –............................ 20 5-6. Schematic Diagram – CD Board –............................... 21 5-7. Printed Wiring Board – TUNER Board –..................... 22 5-8. Schematic Diagram – TUNER Board –....................... 23 5-9. Printed Wiring Board – CONTROL Board –............... 24 5-10. Schematic Diagram – CONTROL Board –.................. 25 5-11. Printed Wiring Boards – PANEL Section –................. 26 5-12. Schematic Diagram – PANEL Section –...................... 27 5-13. Printed Wiring Boards – AUDIO Section –................. 28 5-14. Schematic Diagram – AUDIO Section –...................... 29 6. EXPLODED VIEWS 6-1. Cabinet (Lower) Section................................................. 40 6-2. Cabinet Section-1............................................................ 41 6-3. Cabinet Section-2............................................................ 42 6-4. Cabinet (Upper) Section................................................. 43 6-5. Main Chassis Section...................................................... 44 6-6. CD Block Section............................................................ 45 6-7. Optical Pick-up Section (KSM-213RAP)...................... 46 7. ELECTRICAL PARTS LIST .............................. 47CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous ra- diation exposure. This Compact Disc player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located at the bottom.
Page 2
3 ZS-XN30 ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. Notes on chip component replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing -Keep the temperature of the soldering iron around 270 °C dur- ing repairing. -Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). -Be careful not to apply force on the conductor when soldering or unsoldering. SAFETY CHECK-OUT After correcting the original service problem, perform the follow- ing safety check before releasing the set to the customer: Check the antenna terminals, metal trim, metallized knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The limit indica- tion is 0.75 V, so analog meters must have an accurate low- voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex- amples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suit- able. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 1.5 k Ω 0.15 µF AC voltmeter (0.75 V) To Exposed Metal Parts on Set Earth Ground About CD-Rs/CD-RWs This CD player can play CD-Rs/CD-RWs recorded in the ATRAC3plus/ATRAC3, MP3 or CDDA* format, but playback capability may vary depending on the quality of the disc and the condition of the recording device. *CDDA is the abbreviation for Compact Disc Digital Audio. It is a recording standard used for the Audio CDs. Note Use only the supplied AC power adaptor. Do not use any ot her A C pow er adapt or . Po la r it y o f t he p lug UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. -Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! -Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges oc- cur such as on IC pins, etc. -Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder.
