Sony zs x 3cp ver 1 0
This is the 52 pages manual for sony zs x 3cp ver 1 0.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony zs x 3cp ver 1 0 (Ocr-read)
Page 1
2 ZS-X3CP TABLE OF CONTENTS 1. SERVICING NOTES .............................................. 4 2. GENERAL .................................................................. 5 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 7 3-2. Cabinet Lower, Telescopic Antenna (ANT1) ................. 8 3-3. Main Chassis Section ...................................................... 9 3-4. AUDIO Board, BATTERY Board .................................. 9 3-5. TUNER Board, CONTROL Board ................................. 10 3-6. CDMP3 Board ................................................................. 11 3-7. Optical Pick-up Section .................................................. 11 3-8. Sled Motor Assy (780CP) (M702) .................................. 12 3-9. Optical Pick-up (KSS-900A) .......................................... 12 3-10. Cabinet Front Section ..................................................... 13 3-11. Speaker Unit (L) (SP1), Speaker Unit (R) (SP2) ........... 13 3-12. Lid CD ............................................................................. 14 4. ELECTRICAL ADJUSTMENTS Tuner Section ................................................................. 15 CD Section ..................................................................... 17 5. DIAGRAMS 5-1. Block Diagram – CD Section –.................................... 18 5-2. Block Diagram – TUNER Section –............................ 19 5-3. Block Diagram – MAIN Section –............................... 20 5-4. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 21 5-5. Printed Wiring Boards – CD Section –........................ 23 5-6. Schematic Diagram – CD Section (1/2) –.................... 24 5-7. Schematic Diagram – CD Section (2/2) –.................... 25 5-8. Printed Wiring Board – TUNER Section –.................. 26 5-9. Schematic Diagram – TUNER Section –..................... 27 5-10. Printed Wiring Boards – CONTROL Section –........... 28 5-11. Schematic Diagram – CONTROL Section –................ 29 5-12. Printed Wiring Boards – AUDIO/POWER Section –......................................... 30 5-13. Schematic Diagram – AUDIO/POWER Section –....... 31 5-14. IC Pin Function Description .......................................... 33 6. EXPLODED VIEWS 6-1. Cabinet Lower Section .................................................... 37 6-2. Cabinet Front Section ..................................................... 38 6-3. Cabinet Upper Section-1 ................................................. 39 6-4. Cabinet Upper Section-2 ................................................. 40 6-5. Cabinet Upper Section-3 ................................................. 41 6-6. Main Chassis Section ...................................................... 42 6-7. Optical Pick-up Section (KSM-900AAA) ..................... 43 7. ELECTRICAL PARTS LIST .............................. 44
Page 2
3 ZS-X3CP ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. Notes on chip component replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing -Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. -Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). -Be careful not to apply force on the conductor when soldering or unsoldering. SAFETY CHECK-OUT After correcting the original service problem, perform the follow- ing safety check before releasing the set to the customer: Check the antenna terminals, metal trim, metallized knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The limit indica- tion is 0.75 V, so analog meters must have an accurate low- voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex- amples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suit- able. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 1.5 k Ω 0.15 µF AC voltmeter (0.75 V) To Exposed Metal Parts on Set Earth Ground CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous ra- diation exposure. About CD-Rs/CD-RWs and MP3 files This player can play CD-Rs/CD-RWs recorded in the CD- DA format* and MP3 files recorded in the CD-ROM format, but playback capability may vary depending on the quality of the disc and the condition of the recording device. * CD-DA is the abbreviation for Compact Disc Digital Audio. It is a recording standard used for Audio CDs.
